Last week the NetBSD team has announced the second release candidate for NetBSD 8. Compared to the first one it fixed Intel 10 Gbit ethernet driver bug , includes newly discovered Intel FPU security bug mitigation, as well other kernel and security fixes. Full list of changes since NetBSD 7 can be found here, since initial 8 branch here. Binaries can be downloaded from this location or any of ftp mirrors. Please test it and submit feedback to the NebBSD team.
Category Archives: NetBSD
NetBSD ARM bootable images, new desktop environments, security audit
Lately the NetBSD team puts lots of effort on ARM 64 bit port and some new ARM SoCs support including Allwinner ones. The list of supported Allwinner based boards can be found here. Additionally one can download 32 bit and 64 bit ready-to-go SD card bootable images in http://www.invisible.ca/arm. What is more, NetBSD blog posted an annotated look at a NetBSD Pinebook’s startup.
Finally there is some effort in progress on making Cinnamon desktop environment available for NetBSD!
The Cinnamon Desktop Environment is coming soon to @NetBSD and others on @pkgsrc! It is very fancy and runs well on newer hardware. pic.twitter.com/fb1ccz3KcR
— Youri Mouton (@YouriMouton) May 23, 2018
The last but not the least, security audit of NetBSD’s security stack was performed. It resulted in series of security advisories. They can be found in security page. It is recommended to review them and apply fixes to affected systems.
Running Xorg and wine on VT310-DP
I finally had a chance to run quite stable X server on VT310-DP system. I changed my kernel configuration to use viadrmums driver instead of viadrm which was causing system reboot on X.org server initialization. However there is an issue that mouse pointer is not visible, it is working though on blind clicking (there is an old bug report regarding that but it probably wasn’t look upon since the end of discussion almost four years ago Update: It seems that openchrome officially doesn’t support hardware cursor for integrated graphics in the chipset which is mentioned in the bug report, however it shouldn’t be the case for CN400 chipset, so possibly it is not related bug. Nevertheless, enabling SWCURSOR works as workaround). Thus I had a chance to test my wine build a bit. Building wine instructions still holds true on my configuration for wine-devel package. Unfortunately, it appears not very usable, most applications just crush or start very slowly. Nevertheless, I made a screenshot with notepad running (on wmaker wm).
NetBSD 8.0 RC1 dmesg
I have updated my setup to 8.0 RC1, so I am sharing dmesg with you. Currently my primary computer is based on Ryzen 5 1600 CPU and Biostar X370 GT5 motherboard. Everything except X sets was compiled from source (including packages as I am using pkgsrc). Kernel was compiled from unmodified GENERIC configuration. Graphics card (Radeon RX460) doesn’t seem supported yet, therefore using Xorg is a limited experience.
Copyright (c) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005,
2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017
The NetBSD Foundation, Inc. All rights reserved.
Copyright (c) 1982, 1986, 1989, 1991, 1993
The Regents of the University of California. All rights reserved.
NetBSD 8.0_RC1 (GENERIC) #1: Fri Apr 27 19:06:59 UTC 2018
andrius@localhost:/home/andrius/netbsd-src/sys/arch/amd64/compile/GENERIC
total memory = 32721 MB
avail memory = 31748 MB
cpu_rng: RDSEED
rnd: seeded with 128 bits
timecounter: Timecounters tick every 10.000 msec
Kernelized RAIDframe activated
running cgd selftest aes-xts-256 aes-xts-512 done
timecounter: Timecounter “i8254” frequency 1193182 Hz quality 100
BIOSTAR Group X370GT5 ( )
mainbus0 (root)
ACPI: RSDP 0x00000000000F05B0 000024 (v02 ALASKA)
ACPI: XSDT 0x00000000DC1470A0 0000BC (v01 ALASKA A M I 01072009 AMI 00010013)
ACPI: FACP 0x00000000DC14CA58 000114 (v06 ALASKA A M I 01072009 AMI 00010013)
ACPI BIOS Warning (bug): Optional FADT field Pm2ControlBlock has valid Length but zero Address: 0x0000000000000000/0x1 (20170303/tbfadt-693)
ACPI: DSDT 0x00000000DC1471F0 005862 (v02 ALASKA A M I 01072009 INTL 20120913)
ACPI: FACS 0x00000000DC516E00 000040
ACPI: APIC 0x00000000DC14CB70 0000DE (v03 ALASKA A M I 01072009 AMI 00010013)
ACPI: FPDT 0x00000000DC14CC50 000044 (v01 ALASKA A M I 01072009 AMI 00010013)
ACPI: FIDT 0x00000000DC14CC98 00009C (v01 ALASKA A M I 01072009 AMI 00010013)
ACPI: SSDT 0x00000000DC14CD38 008C4C (v02 AMD AMD ALIB 00000002 MSFT 04000000)
ACPI: SSDT 0x00000000DC155988 002B35 (v01 AMD AMD AOD 00000001 INTL 20120913)
ACPI: MCFG 0x00000000DC1584C0 00003C (v01 ALASKA A M I 01072009 MSFT 00010013)
ACPI: BHMB 0x00000000DC158500 000474 (v01 ALASKA A M I 00000001 AMI 00000001)
ACPI: SSDT 0x00000000DC158978 001A58 (v01 AMD AMD CPU 00000001 AMD 00000001)
ACPI: CRAT 0x00000000DC15A3D0 000BD0 (v01 AMD AMD CRAT 00000001 AMD 00000001)
ACPI: CDIT 0x00000000DC15AFA0 000029 (v01 AMD AMD CDIT 00000001 AMD 00000001)
ACPI: HPET 0x00000000DC15AFD0 000038 (v01 ALASKA A M I 01072009 AMI 00000005)
ACPI: SSDT 0x00000000DC15B008 000024 (v01 AMDFCH FCHZP 00001000 INTL 20120913)
ACPI: UEFI 0x00000000DC15B030 000042 (v01 00000000 00000000)
ACPI: TPM2 0x00000000DC15B078 000034 (v03 ALASKA A M I 00000001 AMI 00000000)
ACPI: IVRS 0x00000000DC15B0B0 0000D0 (v02 AMD AMD IVRS 00000001 AMD 00000000)
ACPI: SSDT 0x00000000DC15B180 0000F8 (v01 AMD AMD PT 00001000 INTL 20120913)
ACPI: SSDT 0x00000000DC15B278 00195E (v01 AMD AmdTable 00000001 INTL 20120913)
ACPI: WSMT 0x00000000DC15CBD8 000028 (v01 ALASKA A M I 01072009 AMI 00010013)
ACPI: Executed 1 blocks of module-level executable AML code
ACPI: Executed 1 blocks of module-level executable AML code
ACPI: 7 ACPI AML tables successfully acquired and loaded
ioapic0 at mainbus0 apid 13: pa 0xfec00000, version 0x21, 24 pins
ioapic1 at mainbus0 apid 14: pa 0xfec01000, version 0x21, 32 pins
cpu0 at mainbus0 apid 0
cpu0: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu0: package 0, core 0, smt 0
cpu1 at mainbus0 apid 1
cpu1: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu1: package 0, core 0, smt 1
cpu2 at mainbus0 apid 2
cpu2: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu2: package 0, core 1, smt 0
cpu3 at mainbus0 apid 3
cpu3: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu3: package 0, core 1, smt 1
cpu4 at mainbus0 apid 4
cpu4: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu4: package 0, core 2, smt 0
cpu5 at mainbus0 apid 5
cpu5: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu5: package 0, core 2, smt 1
cpu6 at mainbus0 apid 8
cpu6: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu6: package 0, core 4, smt 0
cpu7 at mainbus0 apid 9
cpu7: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu7: package 0, core 4, smt 1
cpu8 at mainbus0 apid 10
cpu8: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu8: package 0, core 5, smt 0
cpu9 at mainbus0 apid 11
cpu9: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu9: package 0, core 5, smt 1
cpu10 at mainbus0 apid 12
cpu10: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu10: package 0, core 6, smt 0
cpu11 at mainbus0 apid 13
cpu11: AMD Ryzen 5 1600 Six-Core Processor , id 0x800f11
cpu11: package 0, core 6, smt 1
acpi0 at mainbus0: Intel ACPICA 20170303
acpi0: X/RSDT: OemId <ALASKA, A M I ,01072009>, AslId <AMI ,00010013>
acpi0: invalid PCI address for D01A
acpi0: MCFG: segment 0, bus 0-63, address 0x00000000f8000000
acpi0: SCI interrupting at int 9
timecounter: Timecounter “ACPI-Fast” frequency 3579545 Hz quality 1000
hpet0 at acpi0: high precision event timer (mem 0xfed00000-0xfed00400)
timecounter: Timecounter “hpet0” frequency 14318180 Hz quality 2000
AMDN (PNP0C01) at acpi0 not configured
UMEM (PNP0C02) at acpi0 not configured
APSP (PNP0C02) at acpi0 not configured
attimer1 at acpi0 (TMR, PNP0100): io 0x40-0x43 irq 0
pcppi1 at acpi0 (SPKR, PNP0800): io 0x61
spkr0 at pcppi1: PC Speaker
midi0 at pcppi1: PC speaker
sysbeep0 at pcppi1
SIO1 (PNP0C02) at acpi0 not configured
pckbc1 at acpi0 (PS2K, PNP0303-0) (kbd port): io 0x60,0x64 irq 1
UAR1 (PNP0501) at acpi0 not configured
S900 (PNP0C02) at acpi0 not configured
acpibut0 at acpi0 (PWRB, PNP0C0C-170): ACPI Power Button
GPIO (AMDI0030) at acpi0 not configured
TPM (MSFT0101) at acpi0 not configured
AWR0 (PNP0C02) at acpi0 not configured
ABR0 (PNP0C02) at acpi0 not configured
ABR1 (PNP0C02) at acpi0 not configured
ABR2 (PNP0C02) at acpi0 not configured
ABR3 (PNP0C02) at acpi0 not configured
ABR4 (PNP0C02) at acpi0 not configured
ABR5 (PNP0C02) at acpi0 not configured
ABR6 (PNP0C02) at acpi0 not configured
ABR7 (PNP0C02) at acpi0 not configured
AWR1 (PNP0C02) at acpi0 not configured
ABR8 (PNP0C02) at acpi0 not configured
ABR9 (PNP0C02) at acpi0 not configured
ABRA (PNP0C02) at acpi0 not configured
ABRB (PNP0C02) at acpi0 not configured
ABRC (PNP0C02) at acpi0 not configured
ABRD (PNP0C02) at acpi0 not configured
ABRE (PNP0C02) at acpi0 not configured
ABRF (PNP0C02) at acpi0 not configured
PTIO (AMDIF030) at acpi0 not configured
acpitz0 at acpi0 (THRM)
acpitz0: levels: critical 127.0 C, passive cooling
acpiwmi0 at acpi0 (AOD, PNP0C14-AOD): ACPI WMI Interface
acpiwmibus at acpiwmi0 not configured
ACPI: Enabled 1 GPEs in block 00 to 1F
attimer1: attached to pcppi1
pci0 at mainbus0 bus 0: configuration mode 1
pci0: i/o space, memory space enabled, rd/line, rd/mult, wr/inv ok
amdsmn0 at pci0 dev 0 function 0: AMD Family 17h System Management Network
amdzentemp0 at amdsmn0: AMD CPU Temperature Sensors (Family17h)
vendor 1022 product 1451 (IOMMU system) at pci0 dev 0 function 2 not configured
pchb0 at pci0 dev 1 function 0: vendor 1022 product 1452 (rev. 0x00)
ppb0 at pci0 dev 1 function 1: vendor 1022 product 1453 (rev. 0x00)
ppb0: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x4 @ 2.5GT/s
pci1 at ppb0 bus 1
pci1: i/o space, memory space enabled, rd/line, wr/inv ok
xhci0 at pci1 dev 0 function 0: vendor 1022 product 43b9 (rev. 0x02)
xhci0: interrupting at msi0 vec 0
xhci0: xHCI version 1.10 not known to be supported
usb0 at xhci0: USB revision 3.0
usb1 at xhci0: USB revision 2.0
ahcisata0 at pci1 dev 0 function 1: vendor 1022 product 43b5 (rev. 0x02)
ahcisata0: interrupting at ioapic1 pin 1
ahcisata0: 64-bit DMA
ahcisata0: AHCI revision 1.31, 8 ports, 32 slots, CAP 0xef36ff27<SXS,PSC,SSC,PMD,SPM,SAM,ISS=0x3=Gen3,SCLO,SAL,SALP,SSS,SSNTF,SNCQ,S64A>
atabus0 at ahcisata0 channel 0
atabus1 at ahcisata0 channel 1
atabus2 at ahcisata0 channel 2
atabus3 at ahcisata0 channel 3
atabus4 at ahcisata0 channel 4
atabus5 at ahcisata0 channel 5
atabus6 at ahcisata0 channel 6
atabus7 at ahcisata0 channel 7
ppb1 at pci1 dev 0 function 2: vendor 1022 product 43b0 (rev. 0x02)
ppb1: PCI Express capability version 2 <Upstream Port of PCI-E Switch>
pci2 at ppb1 bus 2
pci2: i/o space, memory space enabled, rd/line, wr/inv ok
ppb2 at pci2 dev 0 function 0: vendor 1022 product 43b4 (rev. 0x02)
ppb2: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x1 @ 5.0GT/s
ppb2: link is x1 @ 2.5GT/s
pci3 at ppb2 bus 3
pci3: i/o space, memory space enabled, rd/line, wr/inv ok
re0 at pci3 dev 0 function 0: RealTek 8168/8111 PCIe Gigabit Ethernet (rev. 0x16)
re0: interrupting at msi1 vec 0
re0: Ethernet address
re0: using 256 tx descriptors
rgephy0 at re0 phy 7: RTL8251 1000BASE-T media interface, rev. 0
rgephy0: 10baseT, 10baseT-FDX, 100baseTX, 100baseTX-FDX, 1000baseT-FDX, auto
ppb3 at pci2 dev 1 function 0: vendor 1022 product 43b4 (rev. 0x02)
ppb3: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x1 @ 5.0GT/s
ppb3: link is x1 @ 2.5GT/s
pci4 at ppb3 bus 4
pci4: i/o space, memory space enabled, rd/line, wr/inv ok
ppb4 at pci4 dev 0 function 0: vendor 1b21 product 1080 (rev. 0x03)
pci5 at ppb4 bus 5
pci5: i/o space, memory space enabled, rd/line, wr/inv ok
ppb5 at pci2 dev 2 function 0: vendor 1022 product 43b4 (rev. 0x02)
ppb5: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x1 @ 5.0GT/s
pci6 at ppb5 bus 6
pci6: i/o space, memory space enabled, rd/line, wr/inv ok
ppb6 at pci2 dev 3 function 0: vendor 1022 product 43b4 (rev. 0x02)
ppb6: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x1 @ 5.0GT/s
pci7 at ppb6 bus 7
pci7: i/o space, memory space enabled, rd/line, wr/inv ok
ppb7 at pci2 dev 4 function 0: vendor 1022 product 43b4 (rev. 0x02)
ppb7: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x2 @ 5.0GT/s
pci8 at ppb7 bus 8
pci8: i/o space, memory space enabled, rd/line, wr/inv ok
ppb8 at pci2 dev 6 function 0: vendor 1022 product 43b4 (rev. 0x02)
ppb8: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x1 @ 5.0GT/s
pci9 at ppb8 bus 9
pci9: i/o space, memory space enabled, rd/line, wr/inv ok
ppb9 at pci2 dev 7 function 0: vendor 1022 product 43b4 (rev. 0x02)
ppb9: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x1 @ 5.0GT/s
ppb9: link is x1 @ 2.5GT/s
pci10 at ppb9 bus 10
pci10: i/o space, memory space enabled, rd/line, wr/inv ok
athn0 at pci10 dev 0 function 0: Atheros AR9287
athn0: rev 2 (2T2R), ROM rev 4, address
athn0: interrupting at ioapic1 pin 3
athn0: 11b rates: 1Mbps 2Mbps 5.5Mbps 11Mbps
athn0: 11g rates: 1Mbps 2Mbps 5.5Mbps 11Mbps 6Mbps 9Mbps 12Mbps 18Mbps 24Mbps 36Mbps 48Mbps 54Mbps
pchb1 at pci0 dev 2 function 0: vendor 1022 product 1452 (rev. 0x00)
pchb2 at pci0 dev 3 function 0: vendor 1022 product 1452 (rev. 0x00)
ppb10 at pci0 dev 3 function 1: vendor 1022 product 1453 (rev. 0x00)
ppb10: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x16 @ 8.0GT/s
ppb10: link is x8 @ 8.0GT/s
pci11 at ppb10 bus 11
pci11: i/o space, memory space enabled, rd/line, wr/inv ok
vga0 at pci11 dev 0 function 0: vendor 1002 product 67ef (rev. 0xcf)
wsdisplay0 at vga0 kbdmux 1: console (80×25, vt100 emulation)
wsmux1: connecting to wsdisplay0
drm at vga0 not configured
hdaudio0 at pci11 dev 0 function 1: HD Audio Controller
hdaudio0: interrupting at msi2 vec 0
hdafg0 at hdaudio0: vendor 1002 product aa01
hdafg0: HDMI00 2ch: Digital Out [Jack]
hdafg0: HDMI01 2ch: Digital Out [Jack]
hdafg0: HDMI02 2ch: Digital Out [Jack]
hdafg0: HDMI03 2ch: Digital Out [Jack]
hdafg0: HDMI04 2ch: Digital Out [Jack]
hdafg0: 2ch/0ch 32000Hz 44100Hz 48000Hz PCM16 AC3
pchb3 at pci0 dev 4 function 0: vendor 1022 product 1452 (rev. 0x00)
pchb4 at pci0 dev 7 function 0: vendor 1022 product 1452 (rev. 0x00)
ppb11 at pci0 dev 7 function 1: vendor 1022 product 1454 (rev. 0x00)
ppb11: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x16 @ 8.0GT/s
pci12 at ppb11 bus 12
pci12: i/o space, memory space enabled, rd/line, wr/inv ok
vendor 1022 product 145a (non-essential instrumentation, subclass 0x00) at pci12 dev 0 function 0 not configured
vendor 1022 product 1456 (miscellaneous crypto) at pci12 dev 0 function 2 not configured
xhci1 at pci12 dev 0 function 3: vendor 1022 product 145c (rev. 0x00)
xhci1: interrupting at msi3 vec 0
xhci1: xHCI version 1.0
usb2 at xhci1: USB revision 3.0
usb3 at xhci1: USB revision 2.0
pchb5 at pci0 dev 8 function 0: vendor 1022 product 1452 (rev. 0x00)
ppb12 at pci0 dev 8 function 1: vendor 1022 product 1454 (rev. 0x00)
ppb12: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x16 @ 8.0GT/s
pci13 at ppb12 bus 13
pci13: i/o space, memory space enabled, rd/line, wr/inv ok
vendor 1022 product 1455 (non-essential instrumentation, subclass 0x00) at pci13 dev 0 function 0 not configured
ahcisata1 at pci13 dev 0 function 2: vendor 1022 product 7901 (rev. 0x51)
ahcisata1: interrupting at ioapic1 pin 18
ahcisata1: 64-bit DMA
ahcisata1: AHCI revision 1.31, 8 ports, 32 slots, CAP 0xf737ff07<PSC,SSC,PMD,FBSS,SPM,SAM,ISS=0x3=Gen3,SCLO,SAL,SALP,SMPS,SSNTF,SNCQ,S64A>
atabus8 at ahcisata1 channel 0
atabus9 at ahcisata1 channel 1
atabus10 at ahcisata1 channel 2
atabus11 at ahcisata1 channel 3
atabus12 at ahcisata1 channel 4
atabus13 at ahcisata1 channel 5
atabus14 at ahcisata1 channel 6
atabus15 at ahcisata1 channel 7
hdaudio1 at pci13 dev 0 function 3: HD Audio Controller
hdaudio1: interrupting at msi4 vec 0
hdafg1 at hdaudio1: vendor 10ec product 0892
hdafg1: DAC00 8ch: Speaker [Jack]
hdafg1: DAC01 2ch: HP Out [Jack]
hdafg1: DIG02 2ch: SPDIF Out [Jack]
hdafg1: ADC03 2ch: Line In [Jack], Mic In [Jack]
hdafg1: ADC04 2ch: Mic In [Jack]
hdafg1: 8ch/2ch 32000Hz 44100Hz 48000Hz 88200Hz 96000Hz 192000Hz PCM16 PCM20 PCM24 AC3
audio0 at hdafg1: full duplex, playback, capture, mmap, independent
hdafg1: Virtual format configured – Format SLINEAR, precision 16, channels 2, frequency 48000
hdafg1: Latency: 128 milliseconds
spkr1 at audio0: PC Speaker (synthesized)
vendor 1022 product 790b (SMBus serial bus, revision 0x59) at pci0 dev 20 function 0 not configured
pcib0 at pci0 dev 20 function 3: vendor 1022 product 790e (rev. 0x51)
pchb6 at pci0 dev 24 function 0: vendor 1022 product 1460 (rev. 0x00)
pchb7 at pci0 dev 24 function 1: vendor 1022 product 1461 (rev. 0x00)
pchb8 at pci0 dev 24 function 2: vendor 1022 product 1462 (rev. 0x00)
pchb9 at pci0 dev 24 function 3: vendor 1022 product 1463 (rev. 0x00)
pchb10 at pci0 dev 24 function 4: vendor 1022 product 1464 (rev. 0x00)
pchb11 at pci0 dev 24 function 5: vendor 1022 product 1465 (rev. 0x00)
pchb12 at pci0 dev 24 function 6: vendor 1022 product 1466 (rev. 0x00)
pchb13 at pci0 dev 24 function 7: vendor 1022 product 1467 (rev. 0x00)
isa0 at pcib0
com0 at isa0 port 0x3f8-0x3ff irq 4: ns16550a, working fifo
acpicpu0 at cpu0: ACPI CPU
acpicpu0: C1: FFH, lat 1 us, pow 0 mW
acpicpu0: C2: I/O, lat 400 us, pow 0 mW
acpicpu0: P0: FFH, lat 1 us, pow 3960 mW, 3200 MHz
acpicpu0: P1: FFH, lat 1 us, pow 2940 mW, 2800 MHz
acpicpu0: P2: FFH, lat 1 us, pow 1350 mW, 1550 MHz
acpicpu0: T0: I/O, lat 1 us, pow 0 mW, 100 %
acpicpu0: T1: I/O, lat 1 us, pow 0 mW, 88 %
acpicpu0: T2: I/O, lat 1 us, pow 0 mW, 76 %
acpicpu0: T3: I/O, lat 1 us, pow 0 mW, 64 %
acpicpu0: T4: I/O, lat 1 us, pow 0 mW, 52 %
acpicpu0: T5: I/O, lat 1 us, pow 0 mW, 40 %
acpicpu0: T6: I/O, lat 1 us, pow 0 mW, 28 %
acpicpu0: T7: I/O, lat 1 us, pow 0 mW, 16 %
acpicpu1 at cpu1: ACPI CPU
acpicpu2 at cpu2: ACPI CPU
acpicpu3 at cpu3: ACPI CPU
acpicpu4 at cpu4: ACPI CPU
acpicpu5 at cpu5: ACPI CPU
acpicpu6 at cpu6: ACPI CPU
acpicpu7 at cpu7: ACPI CPU
acpicpu8 at cpu8: ACPI CPU
acpicpu9 at cpu9: ACPI CPU
acpicpu10 at cpu10: ACPI CPU
acpicpu11 at cpu11: ACPI CPU
timecounter: Timecounter “clockinterrupt” frequency 100 Hz quality 0
ERROR: 336 cycle TSC drift observed
uhub0 at usb0: vendor 1022 (0x1022) xHCI Root Hub (0000), class 9/0, rev 1.00/1.00, addr 0
uhub0: 6 ports with 6 removable, self powered
uhub1 at usb1: vendor 1022 (0x1022) xHCI Root Hub (0000), class 9/0, rev 2.00/1.00, addr 0
uhub1: 14 ports with 14 removable, self powered
uhub2 at usb2: vendor 1022 (0x1022) xHCI Root Hub (0000), class 9/0, rev 1.00/1.00, addr 0
uhub2: 4 ports with 4 removable, self powered
uhub3 at usb3: vendor 1022 (0x1022) xHCI Root Hub (0000), class 9/0, rev 2.00/1.00, addr 0
uhub3: 4 ports with 4 removable, self powered
IPsec: Initialized Security Association Processing.
ahcisata0 port 5: device present, speed: 3.0Gb/s
umass0 at uhub0 port 1 configuration 1 interface 0
umass0: Western Digital (0x1058) Elements 10A8 (0x10a8), rev 3.00/10.42, addr 1
umass0: using SCSI over Bulk-Only
wd0 at atabus5 drive 0
wd0: <SAMSUNG HD161HJ>
wd0: drive supports 16-sector PIO transfers, LBA48 addressing
wd0: 149 GB, 310101 cyl, 16 head, 63 sec, 512 bytes/sect x 312581808 sectors
scsibus0 at umass0: 2 targets, 1 lun per target
sd0 at scsibus0 target 0 lun 0: <WD, Elements 10A8, 1042> disk fixed
sd0: fabricating a geometry
sd0: 931 GB, 953837 cyl, 64 head, 32 sec, 512 bytes/sect x 1953458176 sectors
uhub4 at uhub1 port 2: vendor 05e3 (0x5e3) USB2.0 Hub (0x608), class 9/0, rev 2.00/9.01, addr 2
uhub4: single transaction translator
sd0: fabricating a geometry
wd0: drive supports PIO mode 4, DMA mode 2, Ultra-DMA mode 7
wd0(ahcisata0:5:0): using PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133) (using DMA)
uhub4: 4 ports with 4 removable, self powered
ubt0 at uhub3 port 2
ubt0: vendor 0a12 (0xa12) Bluetooth2.1+EDR CLASS1 (0x01), rev 2.00/52.76, addr 1
umass1 at uhub0 port 2 configuration 1 interface 0
umass1: StoreJet Transcend (0x174c) StoreJet Transcend (0x5106), rev 3.00/80.00, addr 3
umass1: using SCSI over Bulk-Only
scsibus1 at umass1: 2 targets, 1 lun per target
sd1 at scsibus1 target 0 lun 0: <StoreJet, Transcend, 0> disk fixed
sd1: 238 GB, 16383 cyl, 16 head, 63 sec, 512 bytes/sect x 500118192 sectors
sd1: GPT GUID: aa426d16-0d0e-40a1-90e7-9a75f7b5c75f
dk0 at sd1: “67b20926-002a-424f-a169-2c7efc563bb9”, 614401 blocks at 4097, type: msdos
dk1 at sd1: “5d7e40e5-4454-4a98-a81e-c5223d78f161”, 421527550 blocks at 618498, type: <unknown>
dk2 at sd1: “ed7d719c-6ef4-451f-9732-2e4dd981273b”, 35925033 blocks at 464178417, type: <unknown>
dk3 at sd1: “731c9349-02e0-471d-93db-99f63c06afe8”, 42032369 blocks at 422146048, type: ffs
uhidev0 at uhub4 port 2 configuration 1 interface 0
uhidev0: Kensington (0x47d) Kensington USB/PS2 Orbit (0x1022), rev 1.10/4.00, addr 4, iclass 3/1
ums0 at uhidev0: 2 buttons
wsmouse0 at ums0 mux 0
uhidev1 at uhub4 port 3 configuration 1 interface 0
uhidev1: USB (0x1c4f) USB Keykoard (0x02), rev 1.10/1.10, addr 5, iclass 3/1
ukbd0 at uhidev1
wskbd0 at ukbd0: console keyboard, using wsdisplay0
uhidev2 at uhub4 port 3 configuration 1 interface 1
uhidev2: USB (0x1c4f) USB Keykoard (0x02), rev 1.10/1.10, addr 5, iclass 3/0
uhidev2: 2 report ids
uhid0 at uhidev2 reportid 1: input=2, output=0, feature=0
uhid1 at uhidev2 reportid 2: input=1, output=0, feature=0
umass2 at uhub1 port 12 configuration 1 interface 0
umass2: Lexar (0x5dc) USB Flash Drive (0xa81d), rev 2.00/11.00, addr 6
umass2: using SCSI over Bulk-Only
scsibus2 at umass2: 2 targets, 1 lun per target
sd2 at scsibus2 target 0 lun 0: <Lexar, USB Flash Drive, 1100> disk removable
sd2: 7645 MB, 1023 cyl, 255 head, 63 sec, 512 bytes/sect x 15656960 sectors
pad0: outputs: 44100Hz, 16-bit, stereo
audio1 at pad0: half duplex, playback, capture, mmap
pad0: Virtual format configured – Format SLINEAR, precision 16, channels 2, frequency 44100
pad0: Latency: 139 milliseconds
spkr2 at audio1: PC Speaker (synthesized)
WARNING: 2 errors while detecting hardware; check system log.
boot device: sd0
root on sd0a dumps on sd0b
root file system type: ffs
kern.module.path=/stand/amd64/8.0/modules
wsdisplay0: screen 1 added (80×25, vt100 emulation)
wsdisplay0: screen 2 added (80×25, vt100 emulation)
wsdisplay0: screen 3 added (80×25, vt100 emulation)
wsdisplay0: screen 4 added (80×25, vt100 emulation)
NetBSD 8.0 RC1 released
The NetBSD team has announced the first release candidate for NetBSD 8. It has many changes since NetBSD 7, some of highlights include USB3 support (finally!), WAPBL stability and performance improvements, meltdown and spectre mitigations, UEFI bootloader, nvme and various other drivers, lots of updates to 3rd party software, increased ARM boards support. Read more on release announcement or read full list of changes here. You can download binaries from here or any of ftp mirrors. Please test it and submit feedback to the NebBSD team.
NetBSD is 25 years
Besides the 7.1.2 release I have also missed one more event in NetBSD history. It was the 25 years birthday for NetBSD on Wednesday (cvs log history shows first commit from 21st of March, 1993). Happy Birthday to NetBSD team and keep up the good work!
NetBSD 7.1.2 released
NetBSD team announced second security/bugfix update of NetBSD 7.1 branch on 15 of March, 2018 . As usual you can download 7.1.2 version by choosing one of the NetBSD mirrors or torrent files. File hashes can be verified at this location. Release announcement and full list of changes can be found here and here respectively. It is strongly recommended to update your system in case you are running earlier version currently.
NetBSD 7.1.1 released
NetBSD team announced 7.1.1 release on 22 of December, 2017. It is security/critical update for NetBSD 7.1 branch. Download mirrors can be found here. Preferred way to download ISO and USB disk images is using torrent files. Finally file hashes can be verified in this location. Release announcement and changes can be found here and here. It is highly recommended to update your system if you are using 7.1 branch.
Building Wine on NetBSD 8.0 beta with pkgsrc current
For personal purposes I needed to build wine on my VT310-DP board using current pkgsrc package manager. I initially tried to build and install emulators/wine package for this purpose as an “obvious” choice. It contains a build for wine-1.6.2. I face two compilation issues during the build. First build issue was complaining about undefined yywrap variable in tools/wrc/parser.yy.c file. I “fixed” it by commenting out //#undef yywrap.
--- tools/wrc/parser.yy.c 2017-08-19 15:29:22.954733511 +0300 +++ tools/wrc/parser.yy.c 2017-08-19 15:30:39.061280133 +0300 @@ -837,7 +837,7 @@ #include "newstruc.h" #include "parser.tab.h" -#undef yywrap +//#undef yywrap /* Always update the current character position within a line */ #define YY_USER_ACTION char_number+=yyleng; wanted_id = want_id; want_id = 0;
Another one was server/ptrace.c issue. There were two code blocks using dbregs.drX variables (X is a number from 0-7), for example context->debug.i386_regs.dr0 = dbregs.dr0. Compiler was complaining that non of drX variables were defined in the struct. From the code I realized that it was using dbreg struct. Then I checked system’s /usr/include/machine/reg.h file, dbreg struct was defined like this:
/*
* Debug Registers
*
* DR0-DR3 Debug Address Registers
* DR4-DR5 Reserved
* DR6 Debug Status Register
* DR7 Debug Control Register
*/
struct dbreg {
int dr[8];
};
It is visible that that dbreg struct has one dr variable which is an array of int. So I replaced all the dbregs.drX lines with array indexes instead dbregs.dr[X] line. It helped and wine was build. Unfortunately running any executable was failing with an error message: “wine: failed to create the process heap”. I tried to investigate error online but it was usually pointing to some old wine bug and workaround to build a manual Linux kernel which I wasn’t sure how to apply on NetBSD. One thing that caught my eye was that NetBSD has a newer wine package called wine-devel. It builds wine-1.9.18. During wine-devel compilation I didn’t face parser.yy.c issue anymore but ptrace.c one was still the same. I made this modification to the file:
--- ptrace.c 2017-08-19 15:14:09.316982274 +0300 +++ ptrace.c 2017-08-19 15:16:07.746233823 +0300 @@ -675,12 +675,12 @@ context->debug.i386_regs.dr6 = DBREG_DRX((&dbregs), 6); context->debug.i386_regs.dr7 = DBREG_DRX((&dbregs), 7); #else - context->debug.i386_regs.dr0 = dbregs.dr0; - context->debug.i386_regs.dr1 = dbregs.dr1; - context->debug.i386_regs.dr2 = dbregs.dr2; - context->debug.i386_regs.dr3 = dbregs.dr3; - context->debug.i386_regs.dr6 = dbregs.dr6; - context->debug.i386_regs.dr7 = dbregs.dr7; + context->debug.i386_regs.dr0 = dbregs.dr[0]; + context->debug.i386_regs.dr1 = dbregs.dr[1]; + context->debug.i386_regs.dr2 = dbregs.dr[2]; + context->debug.i386_regs.dr3 = dbregs.dr[3]; + context->debug.i386_regs.dr6 = dbregs.dr[6]; + context->debug.i386_regs.dr7 = dbregs.dr[7]; #endif context->flags |= SERVER_CTX_DEBUG_REGISTERS; } @@ -709,14 +709,14 @@ DBREG_DRX((&dbregs), 6) = context->debug.i386_regs.dr6; DBREG_DRX((&dbregs), 7) = context->debug.i386_regs.dr7; #else - dbregs.dr0= context->debug.i386_regs.dr0; - dbregs.dr1 = context->debug.i386_regs.dr1; - dbregs.dr2 = context->debug.i386_regs.dr2; - dbregs.dr3 = context->debug.i386_regs.dr3; - dbregs.dr4 = 0; - dbregs.dr5 = 0; - dbregs.dr6 = context->debug.i386_regs.dr6; - dbregs.dr7 = context->debug.i386_regs.dr7; + dbregs.dr[0] = context->debug.i386_regs.dr0; + dbregs.dr[1] = context->debug.i386_regs.dr1; + dbregs.dr[2] = context->debug.i386_regs.dr2; + dbregs.dr[3] = context->debug.i386_regs.dr3; + dbregs.dr[4] = 0; + dbregs.dr[5] = 0; + dbregs.dr[6] = context->debug.i386_regs.dr6; + dbregs.dr[7] = context->debug.i386_regs.dr7; #endif if (ptrace( PTRACE_SETDBREGS, pid, (caddr_t) &dbregs, 0 ) == -1) file_set_error(); else if (thread->context)
Applying this patch fixed the build and I had a newer version of wine ready. Trying it out proved to be successful for some small Windows executable files I was planning to use. Old wine bug didn’t reoccur. So if you want to build wine on NetBSD 8.0 beta and current pkgsrc I recommend using wine-devel package and apply the patch above if build fails.
NetBSD 8 beta testing
I must admit I haven’t been using NetBSD for any serious workloads for years, partially due to personal reasons as I was living abroad for several years. However, I still spend considerable time to keep up to date installations (8 beta branch currently) and test it on various hardware including attempts to run it in any possible way on hardware which doesn’t seem supported. These attempts sometimes result in few submitted bugs or communication in mailing lists, sometimes it can be just an interesting story to tell. I usually keep NetBSD (amd64) system in one or two external hard drives (USB, thunderbolt) except when system doesn’t support x86-64 extensions or are not x86 in general (have two Alpha CPU based systems but lately they are dormant and I don’t have a chance to test them).
One such non 64-bit test system is my old VIA VT-310DP based computer. I’ve been using since 2008. It is a quite unique board featuring two physical VIA EDEN-N CPUs on mini-itx form factor board (haven’t seen such decision on any other mini-itx board yet, probably it was bold move to enter emerging multi core CPU race from AMD and Intel). Though I was trying to replace it many times with newer boards but eventually it became permanent NetBSD testbed when others went away. Using same system for a long time shows quite a good progress in system stability and support. I’ve started with NetBSD 5 release candidate build which couldn’t boot without multi-CPU support disabled and required ACPI disabled as well for a bit more stability. Even booted the network was completely unstable, USB devices were crashing (most likely ACPI issues) including older 4th based releases. Padlock engine was failing as well. System crash, failed network or USB device error weren’t something uncommon those days. Most of them were fixed for the 6th release, some even on subsequent 5.x releases. One fix I was quite proud to help to resolve myself (specifically multi CPU issue). Just recently I also reported an issue related to RNG refactoring. NetBSD 8.0 beta currently works very well and stable in the terminal. X.org is still a different story but I was never focusing on it as the system integrated graphics is not very capable for such tasks anyway with only 64MB shared memory max avail in BIOS (plus considering weak system performance it is more suitable for background tasks like NAS server for example).
VT-310 custom build kernel dmesg with padlock, viadrm enabledCopyright (c) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005,
2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017
The NetBSD Foundation, Inc. All rights reserved.
Copyright (c) 1982, 1986, 1989, 1991, 1993
The Regents of the University of California. All rights reserved.
NetBSD 8.0_BETA (VT-31ODP) #0: Thu Jul 27 08:34:32 EEST 2017
total memory = 1981 MB
avail memory = 1933 MB
cpu_rng: VIA
rnd: seeded with 128 bits
timecounter: Timecounters tick every 10.000 msec
Kernelized RAIDframe activated
running cgd selftest aes-xts-256 aes-xts-512 done
timecounter: Timecounter “i8254” frequency 1193182 Hz quality 100
VIA Technologies, Inc. CN400-8237 ( )
mainbus0 (root)
ACPI: RSDP 0x00000000000F8940 000014 (v00 CN400 )
ACPI: RSDT 0x000000007BDE3040 00002C (v01 CN400 AWRDACPI 42302E31 AWRD 00000000)
ACPI: FACP 0x000000007BDE30C0 000074 (v01 CN400 AWRDACPI 42302E31 AWRD 00000000)
ACPI: DSDT 0x000000007BDE3180 004D8C (v01 CN400 AWRDACPI 00001000 MSFT 0100000E)
ACPI: FACS 0x000000007BDE0000 000040
ACPI: APIC 0x000000007BDE7F80 000068 (v01 CN400 AWRDACPI 42302E31 AWRD 00000000)
ACPI: 1 ACPI AML tables successfully acquired and loaded
ioapic0 at mainbus0 apid 2: pa 0xfec00000, version 0x3, 24 pins
cpu0 at mainbus0 apid 0
cpu0: VIA Nehemiah, id 0x69a
cpu0: package 0, core 0, smt 0
cpu1 at mainbus0 apid 1
cpu1: VIA Nehemiah, id 0x69a
cpu1: package 0, core 0, smt 0
acpi0 at mainbus0: Intel ACPICA 20170303
acpi0: X/RSDT: OemId <CN400 ,AWRDACPI,42302e31>, AslId <AWRD,00000000>
acpi0: SCI interrupting at int 9
timecounter: Timecounter “ACPI-Fast” frequency 3579545 Hz quality 1000
acpibut0 at acpi0 (PWRB, PNP0C0C): ACPI Power Button
MEM (PNP0C01) at acpi0 not configured
PMIO (PNP0C02) at acpi0 not configured
SYSR (PNP0C02) at acpi0 not configured
attimer1 at acpi0 (TMR, PNP0100): io 0x40-0x43 irq 0
pcppi1 at acpi0 (SPKR, PNP0800): io 0x61
midi0 at pcppi1: PC speaker
sysbeep0 at pcppi1
COPR (PNP0C04) at acpi0 not configured
UAR1 (PNP0501) at acpi0 not configured
UAR2 (PNP0501) at acpi0 not configured
acpifan0 at acpi0 (FAN, PNP0C0B): ACPI Fan
acpitz0 at acpi0 (THRM): cpu0
acpitz0: active cooling level 0: 100.0C
acpitz0: levels: critical 100.0 C, passive 100.0 C
apm0 at acpi0: Power Management spec V1.2
ACPI: Enabled 1 GPEs in block 00 to 0F
attimer1: attached to pcppi1
pci0 at mainbus0 bus 0: configuration mode 1
pci0: i/o space, memory space enabled, rd/line, rd/mult, wr/inv ok
pchb0 at pci0 dev 0 function 0: vendor 1106 product 0259 (rev. 0x00)
agp0 at pchb0: aperture at 0xe8000000, size 0x8000000
pchb1 at pci0 dev 0 function 1: vendor 1106 product 1259 (rev. 0x00)
pchb2 at pci0 dev 0 function 2: vendor 1106 product 2259 (rev. 0x00)
pchb3 at pci0 dev 0 function 3: vendor 1106 product 3259 (rev. 0x00)
pchb4 at pci0 dev 0 function 4: vendor 1106 product 4259 (rev. 0x00)
pchb5 at pci0 dev 0 function 7: vendor 1106 product 7259 (rev. 0x00)
ppb0 at pci0 dev 1 function 0: vendor 1106 product b198 (rev. 0x00)
pci1 at ppb0 bus 1
pci1: i/o space, memory space enabled
vga0 at pci1 dev 0 function 0: vendor 1106 product 3118 (rev. 0x02)
wsdisplay0 at vga0 kbdmux 1: console (80×25, vt100 emulation)
wsmux1: connecting to wsdisplay0
viadrm0 at vga0: VIA CN400 / PM8X0
viadrm0: AGP at 0xe8000000 128MB
viadrm0: Initialized via 2.11.1 20070202
fxp0 at pci0 dev 9 function 0: i82551 Ethernet (rev. 0x10)
fxp0: interrupting at ioapic0 pin 17
fxp0: Ethernet address
inphy0 at fxp0 phy 1: i82555 10/100 media interface, rev. 4
inphy0: 10baseT, 10baseT-FDX, 100baseTX, 100baseTX-FDX, auto
vge0 at pci0 dev 10 function 0: VIA VT612X Gigabit Ethernet (rev. 0x11)
vge0: interrupting at ioapic0 pin 18
vge0: Ethernet address:
ciphy0 at vge0 phy 1: Cicada CS8201 10/100/1000TX PHY, rev. 2
ciphy0: 10baseT, 10baseT-FDX, 100baseTX, 100baseTX-FDX, 1000baseT, 1000baseT-FDX, auto
pci_mem_find: expected type mem, found i/o
viaide0 at pci0 dev 15 function 0: VIA Technologies VT8237 SATA Controller (rev. 0x80)
viaide0: bus-master DMA support present
viaide0: primary channel wired to native-PCI mode
viaide0: using ioapic0 pin 20 for native-PCI interrupt
atabus0 at viaide0 channel 0
viaide0: secondary channel wired to native-PCI mode
atabus1 at viaide0 channel 1
viaide1 at pci0 dev 15 function 1
viaide1: VIA Technologies VT8237 ATA133 controller
viaide1: bus-master DMA support present
viaide1: primary channel configured to compatibility mode
viaide1: primary channel interrupting at ioapic0 pin 14
atabus2 at viaide1 channel 0
viaide1: secondary channel configured to compatibility mode
viaide1: secondary channel ignored (disabled)
uhci0 at pci0 dev 16 function 0: vendor 1106 product 3038 (rev. 0x81)
uhci0: interrupting at ioapic0 pin 21
usb0 at uhci0: USB revision 1.0
uhci1 at pci0 dev 16 function 1: vendor 1106 product 3038 (rev. 0x81)
uhci1: interrupting at ioapic0 pin 21
usb1 at uhci1: USB revision 1.0
uhci2 at pci0 dev 16 function 2: vendor 1106 product 3038 (rev. 0x81)
uhci2: interrupting at ioapic0 pin 21
usb2 at uhci2: USB revision 1.0
uhci3 at pci0 dev 16 function 3: vendor 1106 product 3038 (rev. 0x81)
uhci3: interrupting at ioapic0 pin 21
usb3 at uhci3: USB revision 1.0
ehci0 at pci0 dev 16 function 4: vendor 1106 product 3104 (rev. 0x86)
ehci0: interrupting at ioapic0 pin 21
ehci0: dropped intr workaround enabled
ehci0: BIOS refuses to give up ownership, using force
ehci0: EHCI version 1.0
ehci0: 4 companion controllers, 2 ports each: uhci0 uhci1 uhci2 uhci3
usb4 at ehci0: USB revision 2.0
viapcib0 at pci0 dev 17 function 0: vendor 1106 product 3227 (rev. 0x00)
viapcib0: SMBus found at 0x500 (revision 0x0)
iic0 at viapcib0: I2C bus
auvia0 at pci0 dev 17 function 5: VIA Technologies VT8237 AC’97 Audio (rev 0x60)
auvia0: interrupting at ioapic0 pin 22
auvia0: ac97: VIA Technologies VT1616i codec; headphone, 18 bit DAC, 18 bit ADC, KS Waves 3D
auvia0: ac97: ext id 0x1c1<LDAC,SDAC,CDAC,VRA>
audio0 at auvia0: full duplex, playback, capture, mmap, independent
auvia0: Virtual format configured – Format SLINEAR, precision 16, channels 2, frequency 48000
vr0 at pci0 dev 18 function 0: vendor 1106 product 3065 (rev. 0x78)
vr0: interrupting at ioapic0 pin 23
vr0: Ethernet address:
ukphy0 at vr0 phy 1: OUI 0x0002c6, model 0x0032, rev. 10
ukphy0: 10baseT, 10baseT-FDX, 100baseTX, 100baseTX-FDX, auto
isa0 at viapcib0
com0 at isa0 port 0x3f8-0x3ff irq 4: ns16550a, working fifo
com1 at isa0 port 0x2f8-0x2ff irq 3: ns16550a, working fifo
pckbc0 at isa0 port 0x60-0x64
acpicpu0 at cpu0: ACPI CPU
acpicpu0: C1: HLT, lat 0 us, pow 0 mW
padlock0 at cpu0: VIA PadLock
acpicpu1 at cpu1: ACPI CPU
timecounter: Timecounter “clockinterrupt” frequency 100 Hz quality 0
padlock0: RNG ACE
uhub0 at usb0: vendor 1106 (0x1106) UHCI root hub (0000), class 9/0, rev 1.00/1.00, addr 1
uhub0: 2 ports with 2 removable, self powered
uhub1 at usb1: vendor 1106 (0x1106) UHCI root hub (0000), class 9/0, rev 1.00/1.00, addr 1
uhub1: 2 ports with 2 removable, self powered
uhub2 at usb2IPsec: Initialized Security Association Processing.
: vendor 1106 (0x1106) UHCI root hub (0000), class 9/0, rev 1.00/1.00, addr 1
uhub2: 2 ports with 2 removable, self powered
uhub3 at usb3: vendor 1106 (0x1106) UHCI root hub (0000), class 9/0, rev 1.00/1.00, addr 1
uhub3: 2 ports with 2 removable, self powered
uhub4 at usb4: vendor 1106 (0x1106) EHCI root hub (0000), class 9/0, rev 2.00/1.00, addr 1
uhub4: 8 ports with 8 removable, self powered
viaide0 port 0: device present, speed: 1.5Gb/s
wd0 at atabus0 drive 0
wd0: <SAMSUNG HD160JJ>
wd0: drive supports 16-sector PIO transfers, LBA48 addressing
wd0: 149 GB, 310098 cyl, 16 head, 63 sec, 512 bytes/sect x 312579695 sectors
wd0: 32-bit data port
wd0: drive supports PIO mode 4, DMA mode 2, Ultra-DMA mode 7
wd0(viaide0:0:0): using PIO mode 4, Ultra-DMA mode 6 (Ultra/133) (using DMA)
boot device: wd0
root on wd0a dumps on wd0b
root file system type: ffs
kern.module.path=/stand/i386/8.0/modules
uhidev0 at uhub1 port 1 configuration 1 interface 0
uhidev0: Kensington (0x47d) Kensington USB/PS2 Orbit (0x1022), rev 1.10/4.00, addr 2, iclass 3/1
ums0 at uhidev0: 2 buttons
wsmouse0 at ums0 mux 0
uhidev1 at uhub1 port 2 configuration 1 interface 0
uhidev1: USB (0x1c4f) USB Keykoard (0x02), rev 1.10/1.10, addr 3, iclass 3/1
ukbd0 at uhidev1
wskbd0 at ukbd0: console keyboard, using wsdisplay0
uhidev2 at uhub1 port 2 configuration 1 interface 1
uhidev2: USB (0x1c4f) USB Keykoard (0x02), rev 1.10/1.10, addr 3, iclass 3/0
uhidev2: 2 report ids
uhid0 at uhidev2 reportid 1: input=2, output=0, feature=0
uhid1 at uhidev2 reportid 2: input=1, output=0, feature=0
wsdisplay0: screen 1 added (80×25, vt100 emulation)
wsdisplay0: screen 2 added (80×25, vt100 emulation)
wsdisplay0: screen 3 added (80×25, vt100 emulation)
wsdisplay0: screen 4 added (80×25, vt100 emulation)
Another playground was my Mac Mini system (Late 2014 model, MGEN2AE/A). I tried to boot NetBSD 7 on it over a year ago but the USB 3 was still experimental and I couldn’t find any way to boot into it (still didn’t have thunderbolt hard drive at that time). NetBSD 8 beta branch has xhci driver enabled by default, unfortunately system still hangs on the boot (pretty sure it is related to USB 3 support). I managed to boot into the system by disabling ACPI but without USB support I don’t have any input devices available, so it is literally useless. It is possible to boot into the system from external thunderbolt drive (not sure how is it routed internally but NetBSD manages to identify it the same as SATA connected drive) or internal mac drive. Personally I used USB flash drive to load a bootloader and kept installation on the thunderbolt drive (boot loader can start loading the kernel even if it is in USB drive). Unfortunately till USB 3 support is fixed, dmesg (from the boot without ACPI support) is the only thing I can share here.
Mac Mini dmesgCopyright (c) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005,
2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017
The NetBSD Foundation, Inc. All rights reserved.
Copyright (c) 1982, 1986, 1989, 1991, 1993
The Regents of the University of California. All rights reserved.
NetBSD 8.0_BETA (GENERIC.201708131900Z)
total memory = 8068 MB
avail memory = 7812 MB
cpu_rng: RDRAND
timecounter: Timecounters tick every 10.000 msec
Kernelized RAIDframe activated
running cgd selftest aes-xts-256 aes-xts-512 done
RTC BIOS diagnostic error 0xff<clock_battery,ROM_cksum,config_unit,memory_size,fixed_disk,invalid_time>
timecounter: Timecounter “i8254” frequency 1193182 Hz quality 100
Apple Inc. Macmini7,1 (1.0)
mainbus0 (root)
cpu0 at mainbus0
cpu0: Intel(R) Core(TM) i5-4278U CPU @ 2.60GHz, id 0x40651
cpu0: package 0, core 0, smt 0
pci0 at mainbus0 bus 0: configuration mode 1
pci0: i/o space, memory space enabled, rd/line, rd/mult, wr/inv ok
pchb0 at pci0 dev 0 function 0: vendor 8086 product 0a04 (rev. 0x09)
i915drmkms0 at pci0 dev 2 function 0: vendor 8086 product 0a2e (rev. 0x09)
drm: Memory usable by graphics device = 2048M
drm: Supports vblank timestamp caching Rev 2 (21.10.2013).
drm: Driver supports precise vblank timestamp query.
i915drmkms0: interrupting at irq 11 (i915)
intelfb0 at i915drmkms0
i915drmkms0: info: registered panic notifier
intelfb0: framebuffer at 0xffff80008dd68000, size 1920×1080, depth 32, stride 7680
wsdisplay0 at intelfb0 kbdmux 1: console (default, vt100 emulation)
wsmux1: connecting to wsdisplay0
hdaudio0 at pci0 dev 3 function 0: HD Audio Controller
hdaudio0: interrupting at irq 11
hdaudio0: RIRB timeout
hdaudio0: RIRB timeout
xhci0 at pci0 dev 20 function 0: vendor 8086 product 9c31 (rev. 0x04)
pci_intr_map: no mapping for pin A (line=00)
cannot set up pci_intr_handle_t
xhci0: can’t allocate handler
vendor 8086 product 9c3a (miscellaneous communications, revision 0x04) at pci0 dev 22 function 0 not configured
hdaudio1 at pci0 dev 27 function 0: HD Audio Controller
hdaudio1: interrupting at irq 10
hdafg0 at hdaudio1: vendor 1013 product 4208
hdafg0: DAC00 2ch: Speaker [Built-In]
hdafg0: DAC01 2ch: HP Out [Jack]
hdafg0: DIG02 2ch: SPDIF Out [Jack]
hdafg0: ADC03 2ch: Mic In [Jack]
hdafg0: 2ch/2ch 48000Hz PCM16*
audio0 at hdafg0: full duplex, playback, capture, mmap, independent
hdafg0: Virtual format configured – Format SLINEAR, precision 16, channels 2, frequency 48000
spkr0 at audio0: PC Speaker (synthesized)
ppb0 at pci0 dev 28 function 0: vendor 8086 product 9c10 (rev. 0xe4)
ppb0: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x1 @ 5.0GT/s
pci1 at ppb0 bus 1
pci1: i/o space, memory space enabled, rd/line, wr/inv ok
ppb1 at pci0 dev 28 function 2: vendor 8086 product 9c14 (rev. 0xe4)
ppb1: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x1 @ 5.0GT/s
ppb1: link is x1 @ 2.5GT/s
pci2 at ppb1 bus 2
pci2: i/o space, memory space enabled, rd/line, wr/inv ok
vendor 14e4 product 43a0 (miscellaneous network, revision 0x03) at pci2 dev 0 function 0 not configured
ppb2 at pci0 dev 28 function 3: vendor 8086 product 9c16 (rev. 0xe4)
ppb2: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x1 @ 5.0GT/s
ppb2: link is x1 @ 2.5GT/s
pci3 at ppb2 bus 3
pci3: i/o space, memory space enabled, rd/line, wr/inv ok
bge0 at pci3 dev 0 function 0: Broadcom BCM57766 Gigabit Ethernet
bge0: interrupting at irq 11
bge0: HW config 00081154, 00006014, 00002838, 00000000 00000000
bge0: ASIC unknown BCM57766 (0x57766001), Ethernet address
bge0: setting short Tx thresholds
brgphy0 at bge0 phy 1: BCM57765 1000BASE-T media interface, rev. 1
brgphy0: 10baseT, 10baseT-FDX, 100baseTX, 100baseTX-FDX, 1000baseT, 1000baseT-FDX, auto
sdhc0 at pci3 dev 0 function 1: vendor 14e4 product 16bc (rev. 0x01)
sdhc0: interrupting at irq 11
sdhc0: SDHC 3.0, rev 21, SDMA, 200000 kHz, HS SDR50 DDR50 SDR104 HS200 1.8V 3.0V 3.3V, re-tuning mode 1 (1s timer), 2048 byte blocks
sdmmc0 at sdhc0 slot 0
ppb3 at pci0 dev 28 function 4: vendor 8086 product 9c18 (rev. 0xe4)
ppb3: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x4 @ 5.0GT/s
pci4 at ppb3 bus 4
pci4: i/o space, memory space enabled, rd/line, wr/inv ok
ppb4 at pci4 dev 0 function 0: vendor 8086 product 156d (rev. 0x00)
ppb4: PCI Express capability version 2 <Upstream Port of PCI-E Switch>
pci5 at ppb4 bus 5
pci5: i/o space, memory space enabled, rd/line, wr/inv ok
ppb5 at pci5 dev 0 function 0: vendor 8086 product 156d (rev. 0x00)
ppb5: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x4 @ 2.5GT/s
pci6 at ppb5 bus 6
pci6: i/o space, memory space enabled, rd/line, wr/inv ok
vendor 8086 product 156c (miscellaneous system) at pci6 dev 0 function 0 not configured
ppb6 at pci5 dev 3 function 0: vendor 8086 product 156d (rev. 0x00)
ppb6: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x4 @ 2.5GT/s
pci7 at ppb6 bus 7
pci7: i/o space, memory space enabled, rd/line, wr/inv ok
ppb7 at pci7 dev 0 function 0: vendor 8086 product 1549 (rev. 0x00)
ppb7: PCI Express capability version 2 <Upstream Port of PCI-E Switch>
pci8 at ppb7 bus 8
pci8: i/o space, memory space enabled, rd/line, wr/inv ok
ppb8 at pci8 dev 0 function 0: vendor 8086 product 1549 (rev. 0x00)
ppb8: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x4 @ 5.0GT/s
pci9 at ppb8 bus 9
pci9: i/o space, memory space enabled, rd/line, wr/inv ok
ahcisata0 at pci9 dev 0 function 0: vendor 1b21 product 0612 (rev. 0x01)
ahcisata0: interrupting at irq 11
ahcisata0: 64-bit DMA
ahcisata0: AHCI revision 1.20, 2 ports, 32 slots, CAP 0xeb32ffa1<SXS,CCCS,PSC,SSC,PMD,SPM,ISS=0x3=Gen3,SCLO,SAL,SSS,SSNTF,SNCQ,S64A>
atabus0 at ahcisata0 channel 0
atabus1 at ahcisata0 channel 1
ppb9 at pci5 dev 4 function 0: vendor 8086 product 156d (rev. 0x00)
ppb9: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x4 @ 2.5GT/s
pci10 at ppb9 bus 56
pci10: i/o space, memory space enabled, rd/line, wr/inv ok
ppb10 at pci5 dev 5 function 0: vendor 8086 product 156d (rev. 0x00)
ppb10: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x4 @ 2.5GT/s
pci11 at ppb10 bus 57
pci11: i/o space, memory space enabled, rd/line, wr/inv ok
ppb11 at pci5 dev 6 function 0: vendor 8086 product 156d (rev. 0x00)
ppb11: PCI Express capability version 2 <Downstream Port of PCI-E Switch> x4 @ 2.5GT/s
pci12 at ppb11 bus 106
pci12: i/o space, memory space enabled, rd/line, wr/inv ok
pcib0 at pci0 dev 31 function 0: vendor 8086 product 9c43 (rev. 0x04)
ahcisata1 at pci0 dev 31 function 2: vendor 8086 product 9c03 (rev. 0x04)
ahcisata1: interrupting at irq 11
ahcisata1: 64-bit DMA
ahcisata1: AHCI revision 1.30, 1 port, 32 slots, CAP 0xc734ff00<PSC,SSC,PMD,SAM,ISS=0x3=Gen3,SCLO,SAL,SALP,SNCQ,S64A>
atabus2 at ahcisata1 channel 0
ichsmb0 at pci0 dev 31 function 3: vendor 8086 product 9c22 (rev. 0x04)
ichsmb0: interrupting at irq 11
iic0 at ichsmb0: I2C bus
isa0 at pcib0
com0 at isa0 port 0x3f8-0x3ff irq 4: ns8250 or ns16450, no fifo
attimer0 at isa0 port 0x40-0x43
pcppi0 at isa0 port 0x61
spkr1 at pcppi0: PC Speaker
midi0 at pcppi0: PC speaker
sysbeep0 at pcppi0
attimer0: attached to pcppi0
coretemp0 at cpu0: thermal sensor, 1 C resolution, Tjmax=100
timecounter: Timecounter “clockinterrupt” frequency 100 Hz quality 0
timecounter: Timecounter “TSC” frequency 2600191360 Hz quality 3000
IPsec: Initialized Security Association Processing.
ahcisata0 port 0: device present, speed: 6.0Gb/s
ahcisata1 port 0: device present, speed: 3.0Gb/s
drm: Enabling RC6 states: RC6 on, RC6p off, RC6pp off
wd0 at atabus0 drive 0
wd0: <TS256GSJM500>
wd0: drive supports 2-sector PIO transfers, LBA48 addressing
wd0: 238 GB, 496149 cyl, 16 head, 63 sec, 512 bytes/sect x 500118192 sectors
wd0: GPT GUID: aa426d16-0d0e-40a1-90e7-9a75f7b5c75f
dk0 at wd0: “67b20926-002a-424f-a169-2c7efc563bb9”, 614401 blocks at 4097, type: msdos
dk1 at wd0: “5d7e40e5-4454-4a98-a81e-c5223d78f161”, 421527550 blocks at 618498, type: <unknown>
dk2 at wd0: “ed7d719c-6ef4-451f-9732-2e4dd981273b”, 35925033 blocks at 464178417, type: <unknown>
dk3 at wd0: “731c9349-02e0-471d-93db-99f63c06afe8”, 42032369 blocks at 422146048, type: ffs
wd0: drive supports PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133)
wd0(ahcisata0:0:0): using PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133) (using DMA)
wd1 at atabus2 drive 0
wd1: <APPLE HDD HTS541010A9E662>
wd1: drive supports 16-sector PIO transfers, LBA48 addressing
wd1: 931 GB, 1938021 cyl, 16 head, 63 sec, 512 bytes/sect x 1953525168 sectors
wd1: GPT GUID: 6ff6bde0-2008-46e7-9c6f-171bdb49d5cf
dk4 at wd1: “EFI System Partition”, 409600 blocks at 40, type: msdos
dk5 at wd1: “Customer”, 1951845952 blocks at 409640, type: <unknown>
dk6 at wd1: “Recovery HD”, 1269536 blocks at 1952255592, type: <unknown>
wd1: drive supports PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133)
wd1(ahcisata1:0:0): using PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133) (using DMA)
pad0: outputs: 44100Hz, 16-bit, stereo
audio1 at pad0: half duplex, playback, capture, mmap
pad0: Virtual format configured – Format SLINEAR, precision 16, channels 2, frequency 44100
spkr2 at audio1: PC Speaker (synthesized)
WARNING: 3 errors while detecting hardware; check system log.
boot device: wd0
root on dk3
root file system type: ffs
kern.module.path=/stand/amd64/8.0/modules
warning: no /dev/console
Other two systems I have tried had much better luck and hardware support. The first one is lenovo G50-80 laptop with Intel i3-4030U CPU. I needed to disable secure boot and enable legacy boot support in BIOS but USB3 was working perfectly (which wasn’t the case with in NetBSD 7 experimental support) and I could boot into the system from USB3 port. WIFI setup was also seamless. Looking at dmesg gives a strong hope that system can be quite well supported and usable. But I didn’t go further than that. Major testing was done on my main desktop computer with Gigabyte GA-990XA-UD3 (rev1) motherboard, AMD Opteron 3280 CPU and Radeon RX 460 GPU. I even compiled Mate desktop on it (from pkgsrc). It works really smoothly, all hardware seems to be supported pretty well and it can be used as a desktop system for sure. I haven’t done that for while but I believe I can spend some time in NetBSD again :).
Lenovo G50-80 dmesgCopyright (c) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005,
2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017
The NetBSD Foundation, Inc. All rights reserved.
Copyright (c) 1982, 1986, 1989, 1991, 1993
The Regents of the University of California. All rights reserved.
NetBSD 8.0_BETA (GENERIC) #0: Fri Jul 21 20:33:16 UTC 2017
andrius@localhost:/home/andrius/netbsd-src/sys/arch/amd64/compile/GENERIC
total memory = 16310 MB
avail memory = 15814 MB
cpu_rng: RDRAND
rnd: seeded with 128 bits
timecounter: Timecounters tick every 10.000 msec
Kernelized RAIDframe activated
running cgd selftest aes-xts-256 aes-xts-512 done
RTC BIOS diagnostic error 0x80<clock_battery>
timecounter: Timecounter “i8254” frequency 1193182 Hz quality 100
LENOVO 80L0 (Lenovo G50-80)
mainbus0 (root)
ACPI: RSDP 0x00000000000FE020 000024 (v02 LENOVO)
ACPI: XSDT 0x000000009CFD0188 0000C4 (v01 LENOVO CB-01 00000001 01000013)
ACPI: FACP 0x000000009CFF6000 00010C (v05 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: DSDT 0x000000009CFE1000 00FE68 (v02 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: FACS 0x000000009CF7A000 000040
ACPI: UEFI 0x000000009CFFC000 000042 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: ASF! 0x000000009CFFA000 0000A5 (v32 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: BOOT 0x000000009CFF8000 000028 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: LPIT 0x000000009CFF4000 000094 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: MCFG 0x000000009CFF2000 00003C (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: SSDT 0x000000009CFDB000 000B74 (v02 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: UEFI 0x000000009CFFD000 000236 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: ASPT 0x000000009CFF9000 000034 (v07 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: HPET 0x000000009CFF5000 000038 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: WDAT 0x000000009CFF1000 000224 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: SSDT 0x000000009CFDC000 0004D6 (v02 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: MSDM 0x000000009CFFB000 000055 (v03 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: APIC 0x000000009CFF3000 00008C (v03 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: SSDT 0x000000009CFD5000 005AC3 (v02 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: SSDT 0x000000009CFDD000 00342F (v02 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: DBGP 0x000000009CFF7000 000034 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: DMAR 0x000000009CFD4000 0000F0 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: CSRT 0x000000009CFD3000 0000C4 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: FPDT 0x000000009CFD2000 000044 (v01 LENOVO CB-01 00000001 ACPI 00040000)
ACPI: Executed 7 blocks of module-level executable AML code
ACPI: 5 ACPI AML tables successfully acquired and loaded
ioapic0 at mainbus0 apid 2: pa 0xfec00000, version 0x20, 40 pins
x2APIC available but disabled by DMAR table
cpu0 at mainbus0 apid 0
cpu0: Intel(R) Core(TM) i3-4030U CPU @ 1.90GHz, id 0x40651
cpu0: package 0, core 0, smt 0
cpu1 at mainbus0 apid 2
cpu1: Intel(R) Core(TM) i3-4030U CPU @ 1.90GHz, id 0x40651
cpu1: package 0, core 1, smt 0
cpu2 at mainbus0 apid 1
cpu2: Intel(R) Core(TM) i3-4030U CPU @ 1.90GHz, id 0x40651
cpu2: package 0, core 0, smt 1
cpu3 at mainbus0 apid 3
cpu3: Intel(R) Core(TM) i3-4030U CPU @ 1.90GHz, id 0x40651
cpu3: package 0, core 1, smt 1
acpi0 at mainbus0: Intel ACPICA 20170303
acpi0: X/RSDT: OemId <LENOVO,CB-01 ,00000001>, AslId < ,01000013>
ACPI Error: No handler for Region [ERAM] (0xfffffe845b4b3158) [EmbeddedControl] (20170303/evregion-183)
ACPI Error: Region EmbeddedControl (ID=3) has no handler (20170303/exfldio-323)
ACPI Error: Method parse/execution failed [\_SB.PCI0.LPCB.EC0.BAT0._STA] (Node 0xfffffe845b4ad6f8), AE_NOT_EXIST (20170303/psparse-560)
ACPI Error: Method execution failed [\_SB.PCI0.LPCB.EC0.BAT0._STA] (Node 0xfffffe845b4ad6f8), AE_NOT_EXIST (20170303/uteval-111)
acpi0: MCFG: segment 0, bus 0-255, address 0x00000000e0000000
ACPI: Dynamic OEM Table Load:
ACPI: SSDT 0xFFFFFE845B452808 0003D3 (v02 PmRef Cpu0Cst 00003001 INTL 20121220)
ACPI: Dynamic OEM Table Load:
ACPI: SSDT 0xFFFFFE811D21D808 0005AA (v02 PmRef ApIst 00003000 INTL 20121220)
ACPI: Dynamic OEM Table Load:
ACPI: SSDT 0xFFFFFE811D11FE88 000119 (v02 PmRef ApCst 00003000 INTL 20121220)
ACPI Error: No handler for Region [ERAM] (0xfffffe845b4b3158) [EmbeddedControl] (20170303/evregion-183)
ACPI Error: Region EmbeddedControl (ID=3) has no handler (20170303/exfldio-323)
ACPI Error: Method parse/execution failed [\_SB.PCI0.LPCB.EC0.BAT0._STA] (Node 0xfffffe845b4ad6f8), AE_NOT_EXIST (20170303/psparse-560)
ACPI Error: Method execution failed [\_SB.PCI0.LPCB.EC0.BAT0._STA] (Node 0xfffffe845b4ad6f8), AE_NOT_EXIST (20170303/uteval-111)
acpi0: SCI interrupting at int 9
timecounter: Timecounter “ACPI-Safe” frequency 3579545 Hz quality 900
hpet0 at acpi0: high precision event timer (mem 0xfed00000-0xfed00400)
timecounter: Timecounter “hpet0” frequency 14318180 Hz quality 2000
acpiec0 at acpi0 (EC0, PNP0C09-1): io 0x62,0x66
acpivga0 at acpi0 (GFX0): ACPI Display Adapter
acpiout0 at acpivga0 (DD01, 0x0100): ACPI Display Output Device
acpiout1 at acpivga0 (DD02, 0x0002): ACPI Display Output Device
acpiout2 at acpivga0 (DD03, 0x0300): ACPI Display Output Device
acpiout3 at acpivga0 (DD04, 0x0301): ACPI Display Output Device
acpiout4 at acpivga0 (DD05, 0x0005): ACPI Display Output Device
acpiout5 at acpivga0 (DD06, 0x0006): ACPI Display Output Device
acpiout6 at acpivga0 (DD07, 0x0007): ACPI Display Output Device
acpiout7 at acpivga0 (DD08, 0x0008): ACPI Display Output Device
acpiout8 at acpivga0 (DD09, 0x0009): ACPI Display Output Device
acpiout9 at acpivga0 (DD0A, 0x000a): ACPI Display Output Device
acpiout10 at acpivga0 (DD0B, 0x000b): ACPI Display Output Device
acpiout11 at acpivga0 (DD0C, 0x000c): ACPI Display Output Device
acpiout12 at acpivga0 (DD0D, 0x000d): ACPI Display Output Device
acpiout13 at acpivga0 (DD0E, 0x000e): ACPI Display Output Device
acpiout14 at acpivga0 (DD0F, 0x000f): ACPI Display Output Device
acpiout15 at acpivga0 (DD1F, 0x0410): ACPI Display Output Device
acpiout15: brightness levels: [0-100]
acpivga0: unknown output device acpiout0
acpivga0: unknown output device acpiout1
acpivga0: unknown output device acpiout2
acpivga0: unknown output device acpiout3
acpivga0: unknown output device acpiout4
acpivga0: unknown output device acpiout5
acpivga0: unknown output device acpiout6
acpivga0: unknown output device acpiout7
acpivga0: unknown output device acpiout8
acpivga0: unknown output device acpiout9
acpivga0: unknown output device acpiout10
acpivga0: unknown output device acpiout11
acpivga0: unknown output device acpiout12
acpivga0: unknown output device acpiout13
acpivga0: unknown output device acpiout14
acpivga0: unknown output device acpiout15
acpivga0: connected output devices:
acpivga0: 0x0400: Unknown Output Device, head 0
acpibat0 at acpi0 (BAT0, PNP0C0A-1): ACPI Battery
VPC0 (VPC2004) at acpi0 not configured
FWHD (INT0800) at acpi0 not configured
LDRC (PNP0C02) at acpi0 not configured
attimer1 at acpi0 (TIMR, PNP0100): io 0x40-0x43,0x50-0x53 irq 0
CWDT (INT3F0D) at acpi0 not configured
pckbc1 at acpi0 (PS2K, IDEA0100) (kbd port): io 0x60,0x64 irq 1
pckbc2 at acpi0 (PS2M, SYN2B37) (aux port): irq 12
PDRC (PNP0C02) at acpi0 not configured
acpiacad0 at acpi0 (ADP0, ACPI0003): ACPI AC Adapter
acpilid0 at acpi0 (LID0, PNP0C0D): ACPI Lid Switch
acpibut0 at acpi0 (PWRB, PNP0C0C): ACPI Power Button
PEPD (INT33A1) at acpi0 not configured
PTID (INT340E) at acpi0 not configured
ACPI: Enabled 5 GPEs in block 00 to 7F
pckbd0 at pckbc1 (kbd slot)
pckbc1: using irq 1 for kbd slot
wskbd0 at pckbd0: console keyboard
pms0 at pckbc1 (aux slot)
pms0: Synaptics touchpad version 8.1
pms0: Extended W mode, Palm detect, Multi-finger Report, Multi-finger
pckbc1: using irq 12 for aux slot
wsmouse0 at pms0 mux 0
pci0 at mainbus0 bus 0: configuration mode 1
pci0: i/o space, memory space enabled, rd/line, rd/mult, wr/inv ok
pchb0 at pci0 dev 0 function 0: vendor 8086 product 0a04 (rev. 0x0b)
i915drmkms0 at pci0 dev 2 function 0: vendor 8086 product 0a16 (rev. 0x0b)
drm: Memory usable by graphics device = 2048M
drm: Supports vblank timestamp caching Rev 2 (21.10.2013).
drm: Driver supports precise vblank timestamp query.
ACPI Error: [ECR1] Namespace lookup failure, AE_NOT_FOUND (20170303/psargs-395)
ACPI Error: Method parse/execution failed [\_SB.PCI0.GFX0._DSM] (Node 0xfffffe845b4747c8), AE_NOT_FOUND (20170303/psparse-560)
i915drmkms0: interrupting at msi0 vec 0 (i915)
intelfb0 at i915drmkms0
i915drmkms0: info: registered panic notifier
i915drmkms0: More than 8 outputs detected via ACPI
intelfb0: framebuffer at 0xffff80011d4bc000, size 1366×768, depth 32, stride 5504
wsdisplay0 at intelfb0 kbdmux 1: console (default, vt100 emulation), using wskbd0
wsmux1: connecting to wsdisplay0
hdaudio0 at pci0 dev 3 function 0: HD Audio Controller
hdaudio0: interrupting at msi1 vec 0
hdaudio0: timeout leaving reset state
hdaudio0: device driver failed to attach
xhci0 at pci0 dev 20 function 0: vendor 8086 product 9c31 (rev. 0x04)
xhci0: interrupting at msi1 vec 0
xhci0: xHCI version 1.0
usb0 at xhci0: USB revision 3.0
usb1 at xhci0: USB revision 2.0
vendor 8086 product 9c3a (miscellaneous communications, revision 0x04) at pci0 dev 22 function 0 not configured
hdaudio1 at pci0 dev 27 function 0: HD Audio Controller
hdaudio1: interrupting at msi2 vec 0
hdafg0 at hdaudio1: vendor 14f1 product 510f
hdafg0: DAC00 2ch: Speaker [Built-In]
hdafg0: ADC01 2ch: Mic In [Built-In]
hdafg0: ADC02 2ch: Mic In [Jack]
hdafg0: DAC03 2ch: HP Out [Jack]
hdafg0: 2ch/2ch 44100Hz 48000Hz 96000Hz PCM16 PCM20 PCM24
audio0 at hdafg0: full duplex, playback, capture, mmap, independent
hdafg0: Virtual format configured – Format SLINEAR, precision 16, channels 2, frequency 48000
spkr0 at audio0: PC Speaker (synthesized)
ppb0 at pci0 dev 28 function 0: vendor 8086 product 9c10 (rev. 0xe4)
ppb0: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x1 @ 5.0GT/s
pci1 at ppb0 bus 1
pci1: i/o space, memory space enabled, rd/line, wr/inv ok
ppb1 at pci0 dev 28 function 2: vendor 8086 product 9c14 (rev. 0xe4)
ppb1: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x1 @ 5.0GT/s
ppb1: link is x1 @ 2.5GT/s
pci2 at ppb1 bus 2
pci2: i/o space, memory space enabled, rd/line, wr/inv ok
re0 at pci2 dev 0 function 0: RealTek 8168/8111 PCIe Gigabit Ethernet (rev. 0x10)
re0: interrupting at msi3 vec 0
re0: Unknown revision (0x50800000)
re0: Ethernet address
re0: using 256 tx descriptors
rgephy0 at re0 phy 7: RTL8251 1000BASE-T media interface, rev. 0
rgephy0: 10baseT, 10baseT-FDX, 100baseTX, 100baseTX-FDX, 1000baseT-FDX, auto
ppb2 at pci0 dev 28 function 3: vendor 8086 product 9c16 (rev. 0xe4)
ppb2: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x1 @ 5.0GT/s
ppb2: link is x1 @ 2.5GT/s
pci3 at ppb2 bus 3
pci3: i/o space, memory space enabled, rd/line, wr/inv ok
iwm0 at pci3 dev 0 function 0: vendor 8086 product 08b4 (rev. 0x93)
iwm0: interrupting at msi4 vec 0
pcib0 at pci0 dev 31 function 0: vendor 8086 product 9c43 (rev. 0x04)
ahcisata0 at pci0 dev 31 function 2: vendor 8086 product 9c03 (rev. 0x04)
ahcisata0: interrupting at ioapic0 pin 19
ahcisata0: 64-bit DMA
ahcisata0: AHCI revision 1.30, 4 ports, 32 slots, CAP 0xc734ff03<PSC,SSC,PMD,SAM,ISS=0x3=Gen3,SCLO,SAL,SALP,SNCQ,S64A>
atabus0 at ahcisata0 channel 0
atabus1 at ahcisata0 channel 1
ichsmb0 at pci0 dev 31 function 3: vendor 8086 product 9c22 (rev. 0x04)
ichsmb0: interrupting at ioapic0 pin 18
iic0 at ichsmb0: I2C bus
isa0 at pcib0
pcppi0 at isa0 port 0x61
spkr1 at pcppi0: PC Speaker
midi0 at pcppi0: PC speaker
sysbeep0 at pcppi0
attimer1: attached to pcppi0
acpicpu0 at cpu0: ACPI CPU
acpicpu0: C1: FFH, lat 1 us, pow 1000 mW
acpicpu0: C2: FFH, lat 148 us, pow 200 mW
acpicpu0: C3: FFH, lat 506 us, pow 200 mW
acpicpu0: P0: FFH, lat 10 us, pow 15000 mW, 1900 MHz
acpicpu0: P1: FFH, lat 10 us, pow 13939 mW, 1800 MHz
acpicpu0: P2: FFH, lat 10 us, pow 13047 mW, 1700 MHz
acpicpu0: P3: FFH, lat 10 us, pow 12172 mW, 1600 MHz
acpicpu0: P4: FFH, lat 10 us, pow 11172 mW, 1500 MHz
acpicpu0: P5: FFH, lat 10 us, pow 10334 mW, 1400 MHz
acpicpu0: P6: FFH, lat 10 us, pow 9516 mW, 1300 MHz
acpicpu0: P7: FFH, lat 10 us, pow 8712 mW, 1200 MHz
acpicpu0: P8: FFH, lat 10 us, pow 7789 mW, 1100 MHz
acpicpu0: P9: FFH, lat 10 us, pow 7021 mW, 1000 MHz
acpicpu0: P10: FFH, lat 10 us, pow 6270 mW, 900 MHz
acpicpu0: P11: FFH, lat 10 us, pow 5537 mW, 800 MHz
acpicpu0: P12: FFH, lat 10 us, pow 4688 mW, 779 MHz
acpicpu0: T0: I/O, lat 1 us, pow 0 mW, 100 %
acpicpu0: T1: I/O, lat 1 us, pow 0 mW, 88 %
acpicpu0: T2: I/O, lat 1 us, pow 0 mW, 76 %
acpicpu0: T3: I/O, lat 1 us, pow 0 mW, 64 %
acpicpu0: T4: I/O, lat 1 us, pow 0 mW, 52 %
acpicpu0: T5: I/O, lat 1 us, pow 0 mW, 40 %
acpicpu0: T6: I/O, lat 1 us, pow 0 mW, 28 %
acpicpu0: T7: I/O, lat 1 us, pow 0 mW, 16 %
coretemp0 at cpu0: thermal sensor, 1 C resolution, Tjmax=100
acpicpu1 at cpu1: ACPI CPU
coretemp1 at cpu1: thermal sensor, 1 C resolution, Tjmax=100
acpicpu2 at cpu2: ACPI CPU
acpicpu3 at cpu3: ACPI CPU
DRM error in intel_uncore_check_errors: Unclaimed register before interrupt
timecounter: Timecounter “clockinterrupt” frequency 100 Hz quality 0
timecounter: Timecounter “TSC” frequency 1895732060 Hz quality 3000
uhub0 at usb0: vendor 8086 (0x8086) xHCI Root Hub (0000), class 9/0, rev 1.00/1.00, addr 0
uhub0: 4 ports with 4 removable, self powered
uhub1 at usb1: vendor 8086 (0x8086) xHCI Root Hub (0000), class 9/0, rev 2.00/1.00, addr 0
uhub1: 9 ports with 9 removable, self powered
acpiacad0: AC adapter online.
IPsec: Initialized Security Association Processing.
ahcisata0 port 0: device present, speed: 6.0Gb/s
ahcisata0 port 1: device present, speed: 1.5Gb/s
drm: Enabling RC6 states: RC6 on, RC6p off, RC6pp off
wd0 at atabus0 drive 0
wd0: <WDC WD5000LPCX-24C6HT0>
wd0: drive supports 16-sector PIO transfers, LBA48 addressing
wd0: 465 GB, 969021 cyl, 16 head, 63 sec, 512 bytes/sect x 976773168 sectors
umass0 at uhub0 port 1 configuration 1 interface 0
umass0: Western Digital (0x1058) Elements 10A8 (0x10a8), rev 3.00/10.42, addr 1
umass0: using SCSI over Bulk-Only
uhidev0 at uhub1 port 1 configuration 1 interface 0
uhidev0: Logitech (0x46d) USB Receiver (0xc52b), rev 2.00/12.03, addr 2, iclass 3/1
scsibus0 at umass0: 2 targets, 1 lun per target
ukbd0 at uhidev0
sd0 at scsibus0 target 0 lun 0: <WD, Elements 10A8, 1042> disk fixed
sd0: fabricating a geometry
sd0: 931 GB, 953837 cyl, 64 head, 32 sec, 512 bytes/sect x 1953458176 sectors
sd0: fabricating a geometry
wd0: GPT GUID: f747ee4d-1956-429e-b0c7-42bece5bdc0b
dk0 at wd0: “Basic data partition”, 2048000 blocks at 2048, type: <unknown>
dk1 at wd0: “EFI system partition”, 532480 blocks at 2050048, type: msdos
dk2 at wd0: “b077eada-048e-4e51-bf90-1538ba79b1fb”, 2048000 blocks at 2582528, type: <unknown>
wd0: wedge named ‘Basic data partition’ already existed, using ‘b077eada-048e-4e51-bf90-1538ba79b1fb’
dk3 at wd0: “Microsoft reserved partition”, 262144 blocks at 4630528, type: <unknown>
dk4 at wd0: “6c826e57-0ee1-4609-b1dd-662eecffb680”, 888635392 blocks at 4892672, type: <unknown>
wd0: wedge named ‘Basic data partition’ already existed, using ‘6c826e57-0ee1-4609-b1dd-662eecffb680’
dk5 at wd0: “123470c0-30a6-4c0f-b7a7-00239c6c2e27”, 52428800 blocks at 893528064, type: <unknown>
wd0: wedge named ‘Basic data partition’ already existed, using ‘123470c0-30a6-4c0f-b7a7-00239c6c2e27’
dk6 at wd0: “4b0b1fc8-b38c-4ed2-9393-617233127877”, 30816256 blocks at 945956864, type: <unknown>
wd0: wedge named ‘Basic data partition’ already existed, using ‘4b0b1fc8-b38c-4ed2-9393-617233127877’
wd0: drive supports PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133)
wd0(ahcisata0:0:0): using PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133) (using DMA)
atapibus0 at atabus1: 1 targets
cd0 at atapibus0 drive 0: <MATSHITA DVD-RAM UJ8FBS, 8SSDX0E66033P1CC5244, F801> cdrom removable
cd0: drive supports PIO mode 4, DMA mode 2, Ultra-DMA mode 5 (Ultra/100)
cd0(ahcisata0:1:0): using PIO mode 4, DMA mode 2, Ultra-DMA mode 5 (Ultra/100) (using DMA)
wskbd1 at ukbd0 mux 1
wskbd1: connecting to wsdisplay0
uhidev1 at uhub1 port 1 configuration 1 interface 1
uhidev1: Logitech (0x46d) USB Receiver (0xc52b), rev 2.00/12.03, addr 2, iclass 3/1
uhidev1: 8 report ids
ums0 at uhidev1 reportid 2: 16 buttons, W and Z dirs
wsmouse1 at ums0 mux 0
uhid0 at uhidev1 reportid 3: input=4, output=0, feature=0
uhid1 at uhidev1 reportid 4: input=1, output=0, feature=0
uhid2 at uhidev1 reportid 8: input=1, output=0, feature=0
uhidev2 at uhub1 port 1 configuration 1 interface 2
uhidev2: Logitech (0x46d) USB Receiver (0xc52b), rev 2.00/12.03, addr 2, iclass 3/0
uhidev2: 33 report ids
uhid3 at uhidev2 reportid 16: input=6, output=6, feature=0
uhid4 at uhidev2 reportid 17: input=19, output=19, feature=0
uhid5 at uhidev2 reportid 32: input=14, output=14, feature=0
uhid6 at uhidev2 reportid 33: input=31, output=31, feature=0
ugen0 at uhub1 port 4
ugen0: Generic (0xbda) USB2.0-CRW (0x129), rev 2.00/39.60, addr 3
uvideo0 at uhub1 port 6 configuration 1 interface 0: Bsion Corp. (0x5986) Lenovo EasyCamera (0x55d), rev 2.00/36.55, addr 4
video0 at uvideo0: Bsion Corp. (0x5986) Lenovo EasyCamera (0x55d), rev 2.00/36.55, addr 4
ubt0 at uhub1 port 7
ubt0: vendor 8087 (0x8087) product 07dc (0x7dc), rev 2.00/0.01, addr 5
pad0: outputs: 44100Hz, 16-bit, stereo
audio1 at pad0: half duplex, playback, capture, mmap
pad0: Virtual format configured – Format SLINEAR, precision 16, channels 2, frequency 44100
spkr2 at audio1: PC Speaker (synthesized)
WARNING: 23 errors while detecting hardware; check system log.
boot device: sd0
root on sd0a dumps on sd0b
root file system type: ffs
kern.module.path=/stand/amd64/8.0/modules
iwm0: hw rev 0x160, fw ver 17.352738.0, address f4:06:69:62:cf:50
iwm0: 11a rates: 6Mbps 9Mbps 12Mbps 18Mbps 24Mbps 36Mbps 48Mbps 54Mbps
iwm0: 11b rates: 1Mbps 2Mbps 5.5Mbps 11Mbps
iwm0: 11g rates: 1Mbps 2Mbps 5.5Mbps 11Mbps 6Mbps 9Mbps 12Mbps 18Mbps 24Mbps 36Mbps 48Mbps 54Mbps
Opteron 3280 dmesg
Copyright (c) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005,
2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017
The NetBSD Foundation, Inc. All rights reserved.
Copyright (c) 1982, 1986, 1989, 1991, 1993
The Regents of the University of California. All rights reserved.
NetBSD 8.0_BETA (GENERIC) #0: Fri Jul 21 20:33:16 UTC 2017
andrius@localhost:/home/andrius/netbsd-src/sys/arch/amd64/compile/GENERIC
total memory = 8108 MB
avail memory = 7850 MB
timecounter: Timecounters tick every 10.000 msec
Kernelized RAIDframe activated
running cgd selftest aes-xts-256 aes-xts-512 done
timecounter: Timecounter “i8254” frequency 1193182 Hz quality 100
Gigabyte Technology Co., Ltd. GA-990XA-UD3 ( )
mainbus0 (root)
ACPI: RSDP 0x00000000000F6B00 000014 (v00 GBT )
ACPI: RSDT 0x00000000BFDD1000 00004C (v01 GBT GBTUACPI 42302E31 GBTU 01010101)
ACPI: FACP 0x00000000BFDD1080 000074 (v01 GBT GBTUACPI 42302E31 GBTU 01010101)
ACPI: DSDT 0x00000000BFDD1100 007A4B (v01 GBT GBTUACPI 00001000 MSFT 03000000)
ACPI: FACS 0x00000000BFDA0000 000040
ACPI: MSDM 0x00000000BFDD8C40 000055 (v03 GBT GBTUACPI 42302E31 GBTU 01010101)
ACPI: HPET 0x00000000BFDD8CC0 000038 (v01 GBT GBTUACPI 42302E31 GBTU 00000098)
ACPI: MCFG 0x00000000BFDD8D00 00003C (v01 GBT GBTUACPI 42302E31 GBTU 01010101)
ACPI: EUDS 0x00000000BFDD8D80 000740 (v01 GBT 00000000 00000000)
ACPI: MATS 0x00000000BFDD94C0 000034 (v01 GBT 00000000 00000000)
ACPI: TAMG 0x00000000BFDD9530 000182 (v01 GBT GBT B0 5455312E BG?? 53450101)
ACPI: APIC 0x00000000BFDD8B80 0000BC (v01 GBT GBTUACPI 42302E31 GBTU 01010101)
ACPI: MATS 0x00000000BFDD96C0 006209 (v01 MATS RCM 80000001 INTL 20061109)
ACPI: SSDT 0x00000000BFDDF940 001714 (v01 AMD POWERNOW 00000001 AMD 00000001)
ACPI: 2 ACPI AML tables successfully acquired and loaded
ioapic0 at mainbus0 apid 8: pa 0xfec00000, version 0x21, 24 pins
cpu0 at mainbus0 apid 0
cpu0: AMD Opteron(tm) Processor 3280 , id 0x600f12
cpu0: package 0, core 0, smt 0
cpu1 at mainbus0 apid 1
cpu1: AMD Opteron(tm) Processor 3280 , id 0x600f12
cpu1: package 0, core 3, smt 0
cpu2 at mainbus0 apid 2
cpu2: AMD Opteron(tm) Processor 3280 , id 0x600f12
cpu2: package 0, core 5, smt 0
cpu3 at mainbus0 apid 3
cpu3: AMD Opteron(tm) Processor 3280 , id 0x600f12
cpu3: package 0, core 2, smt 0
cpu4 at mainbus0 apid 4
cpu4: AMD Opteron(tm) Processor 3280 , id 0x600f12
cpu4: package 0, core 4, smt 0
cpu5 at mainbus0 apid 5
cpu5: AMD Opteron(tm) Processor 3280 , id 0x600f12
cpu5: package 0, core 1, smt 0
cpu6 at mainbus0 apid 6
cpu6: AMD Opteron(tm) Processor 3280 , id 0x600f12
cpu6: package 0, core 6, smt 0
cpu7 at mainbus0 apid 7
cpu7: AMD Opteron(tm) Processor 3280 , id 0x600f12
cpu7: package 0, core 7, smt 0
acpi0 at mainbus0: Intel ACPICA 20170303
acpi0: X/RSDT: OemId <GBT ,GBTUACPI,42302e31>, AslId <GBTU,01010101>
acpi0: MCFG: segment 0, bus 0-255, address 0x00000000e0000000
acpi0: SCI interrupting at int 9
timecounter: Timecounter “ACPI-Fast” frequency 3579545 Hz quality 1000
hpet0 at acpi0: high precision event timer (mem 0xfed00000-0xfed00400)
timecounter: Timecounter “hpet0” frequency 14318180 Hz quality 2000
acpibut0 at acpi0 (PWRB, PNP0C0C): ACPI Power Button
SYSR (PNP0C02) at acpi0 not configured
PMIO (PNP0C02) at acpi0 not configured
attimer1 at acpi0 (TMR, PNP0100): io 0x40-0x43
pcppi1 at acpi0 (SPKR, PNP0800): io 0x61
spkr0 at pcppi1: PC Speaker
midi0 at pcppi1: PC speaker
sysbeep0 at pcppi1
acpiwmi0 at acpi0 (WMI1, PNP0C14-MXM2): ACPI WMI Interface
acpiwmibus at acpiwmi0 not configured
UAR1 (PNP0501) at acpi0 not configured
EXPL (PNP0C02) at acpi0 not configured
MEM (PNP0C01) at acpi0 not configured
acpiwmi1 at acpi0 (AOD, PNP0C14-0): ACPI WMI Interface
acpiwmibus at acpiwmi1 not configured
attimer1: attached to pcppi1
pci0 at mainbus0 bus 0: configuration mode 1
pci0: i/o space, memory space enabled, rd/line, rd/mult, wr/inv ok
pchb0 at pci0 dev 0 function 0: vendor 1002 product 5a14 (rev. 0x02)
ppb0 at pci0 dev 2 function 0: vendor 1002 product 5a16 (rev. 0x00)
ppb0: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x16 @ 5.0GT/s
ppb0: link is x8 @ 5.0GT/s
pci1 at ppb0 bus 1
pci1: i/o space, memory space enabled, rd/line, wr/inv ok
vga0 at pci1 dev 0 function 0: vendor 1002 product 67ef (rev. 0xcf)
wsdisplay0 at vga0 kbdmux 1: console (80×25, vt100 emulation)
wsmux1: connecting to wsdisplay0
drm at vga0 not configured
hdaudio0 at pci1 dev 0 function 1: HD Audio Controller
hdaudio0: interrupting at ioapic0 pin 19
hdafg0 at hdaudio0: vendor 1002 product aa01
hdafg0: HDMI00 2ch: Digital Out [Jack]
hdafg0: HDMI01 2ch: Digital Out [Jack]
hdafg0: HDMI02 2ch: Digital Out [Jack]
hdafg0: HDMI03 2ch: Digital Out [Jack]
hdafg0: HDMI04 2ch: Digital Out [Jack]
hdafg0: 2ch/0ch 32000Hz 44100Hz 48000Hz PCM16 AC3
ppb1 at pci0 dev 4 function 0: vendor 1002 product 5a18 (rev. 0x00)
ppb1: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x2 @ 5.0GT/s
ppb1: link is x1 @ 5.0GT/s
pci2 at ppb1 bus 2
pci2: i/o space, memory space enabled, rd/line, wr/inv ok
xhci0 at pci2 dev 0 function 0: vendor 1b6f product 7023 (rev. 0x01)
xhci0: interrupting at ioapic0 pin 16
xhci0: xHCI version 1.0
usb0 at xhci0: USB revision 3.0
usb1 at xhci0: USB revision 2.0
ppb2 at pci0 dev 9 function 0: vendor 1002 product 5a1c (rev. 0x00)
ppb2: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x1 @ 5.0GT/s
ppb2: link is x1 @ 2.5GT/s
pci3 at ppb2 bus 3
pci3: i/o space, memory space enabled, rd/line, wr/inv ok
re0 at pci3 dev 0 function 0: RealTek 8168/8111 PCIe Gigabit Ethernet (rev. 0x06)
re0: interrupting at ioapic0 pin 17
re0: Ethernet address
re0: using 256 tx descriptors
rgephy0 at re0 phy 7: RTL8169S/8110S/8211 1000BASE-T media interface, rev. 5
rgephy0: 10baseT, 10baseT-FDX, 100baseTX, 100baseTX-FDX, 1000baseT, 1000baseT-FDX, auto
ppb3 at pci0 dev 10 function 0: vendor 1002 product 5a1d (rev. 0x00)
ppb3: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x1 @ 5.0GT/s
pci4 at ppb3 bus 4
pci4: i/o space, memory space enabled, rd/line, wr/inv ok
xhci1 at pci4 dev 0 function 0: vendor 1b6f product 7023 (rev. 0x01)
xhci1: interrupting at ioapic0 pin 18
xhci1: xHCI version 1.0
usb2 at xhci1: USB revision 3.0
usb3 at xhci1: USB revision 2.0
ahcisata0 at pci0 dev 17 function 0: vendor 1002 product 4393 (rev. 0x40)
ahcisata0: interrupting at ioapic0 pin 19
ahcisata0: 64-bit DMA
ahcisata0: AHCI revision 1.20, 6 ports, 32 slots, CAP 0xf732ff05<PSC,SSC,PMD,SPM,ISS=0x3=Gen3,SCLO,SAL,SALP,SMPS,SSNTF,SNCQ,S64A>
atabus0 at ahcisata0 channel 0
atabus1 at ahcisata0 channel 1
atabus2 at ahcisata0 channel 2
atabus3 at ahcisata0 channel 3
atabus4 at ahcisata0 channel 4
atabus5 at ahcisata0 channel 5
ohci0 at pci0 dev 18 function 0: vendor 1002 product 4397 (rev. 0x00)
ohci0: interrupting at ioapic0 pin 18
ohci0: OHCI version 1.0, legacy support
usb4 at ohci0: USB revision 1.0
ehci0 at pci0 dev 18 function 2: vendor 1002 product 4396 (rev. 0x00)
ehci0: interrupting at ioapic0 pin 17
ehci0: dropped intr workaround enabled
ehci0: EHCI version 1.0
ehci0: companion controller, 5 ports each: ohci0
usb5 at ehci0: USB revision 2.0
ohci1 at pci0 dev 19 function 0: vendor 1002 product 4397 (rev. 0x00)
ohci1: interrupting at ioapic0 pin 18
ohci1: OHCI version 1.0, legacy support
usb6 at ohci1: USB revision 1.0
ehci1 at pci0 dev 19 function 2: vendor 1002 product 4396 (rev. 0x00)
ehci1: interrupting at ioapic0 pin 17
ehci1: dropped intr workaround enabled
ehci1: EHCI version 1.0
ehci1: companion controller, 5 ports each: ohci1
usb7 at ehci1: USB revision 2.0
piixpm0 at pci0 dev 20 function 0: vendor 1002 product 4385 (rev. 0x42)
piixpm0: polling (SB800)
iic0 at piixpm0: I2C bus
iic1 at piixpm0: I2C bus
iic2 at piixpm0: I2C bus
iic3 at piixpm0: I2C bus
hdaudio1 at pci0 dev 20 function 2: HD Audio Controller
hdaudio1: interrupting at ioapic0 pin 16
hdafg1 at hdaudio1: vendor 10ec product 0889
hdafg1: DAC00 8ch: Speaker [Jack]
hdafg1: DAC01 2ch: HP Out [Jack]
hdafg1: DIG02 2ch: SPDIF Out [Jack]
hdafg1: DIG03 2ch: SPDIF Out [Built-In]
hdafg1: ADC04 2ch: Line In [Jack], Mic In [Jack]
hdafg1: ADC05 2ch: Mic In [Jack]
hdafg1: 8ch/2ch 32000Hz 44100Hz 48000Hz 88200Hz 96000Hz 192000Hz PCM16 PCM20 PCM24 AC3
audio0 at hdafg1: full duplex, playback, capture, mmap, independent
hdafg1: Virtual format configured – Format SLINEAR, precision 16, channels 2, frequency 48000
spkr1 at audio0: PC Speaker (synthesized)
pcib0 at pci0 dev 20 function 3: vendor 1002 product 439d (rev. 0x40)
ppb4 at pci0 dev 20 function 4: vendor 1002 product 4384 (rev. 0x40)
pci5 at ppb4 bus 5
pci5: i/o space, memory space enabled
ohci2 at pci0 dev 20 function 5: vendor 1002 product 4399 (rev. 0x00)
ohci2: interrupting at ioapic0 pin 18
ohci2: OHCI version 1.0, legacy support
usb8 at ohci2: USB revision 1.0
ppb5 at pci0 dev 21 function 0: vendor 1002 product 43a0 (rev. 0x00)
ppb5: PCI Express capability version 2 <Root Port of PCI-E Root Complex> x4 @ 2.5GT/s
pci6 at ppb5 bus 6
pci6: i/o space, memory space enabled, rd/line, wr/inv ok
ohci3 at pci0 dev 22 function 0: vendor 1002 product 4397 (rev. 0x00)
ohci3: interrupting at ioapic0 pin 18
ohci3: OHCI version 1.0, legacy support
usb9 at ohci3: USB revision 1.0
ehci2 at pci0 dev 22 function 2: vendor 1002 product 4396 (rev. 0x00)
ehci2: interrupting at ioapic0 pin 17
ehci2: dropped intr workaround enabled
ehci2: EHCI version 1.0
ehci2: companion controller, 4 ports each: ohci3
usb10 at ehci2: USB revision 2.0
pchb1 at pci0 dev 24 function 0: vendor 1022 product 1600 (rev. 0x00)
pchb2 at pci0 dev 24 function 1: vendor 1022 product 1601 (rev. 0x00)
pchb3 at pci0 dev 24 function 2: vendor 1022 product 1602 (rev. 0x00)
amdnb_misc0 at pci0 dev 24 function 3: AMD NB Misc Configuration
amdtemp0 at amdnb_misc0: AMD CPU Temperature Sensors (Family15h)
pchb4 at pci0 dev 24 function 4: vendor 1022 product 1604 (rev. 0x00)
pchb5 at pci0 dev 24 function 5: vendor 1022 product 1605 (rev. 0x00)
isa0 at pcib0
com0 at isa0 port 0x3f8-0x3ff irq 4: ns16550a, working fifo
pckbc0 at isa0 port 0x60-0x64
acpicpu0 at cpu0: ACPI CPU
acpicpu0: C1: HLT, lat 0 us, pow 0 mW
acpicpu0: C2: I/O, lat 100 us, pow 0 mW
acpicpu0: P0: FFH, lat 4 us, pow 7087 mW, 2400 MHz
acpicpu0: P1: FFH, lat 4 us, pow 5678 mW, 2100 MHz
acpicpu0: P2: FFH, lat 4 us, pow 4902 mW, 1900 MHz
acpicpu0: P3: FFH, lat 4 us, pow 4050 mW, 1600 MHz
acpicpu0: P4: FFH, lat 4 us, pow 3500 mW, 1400 MHz
acpicpu1 at cpu1: ACPI CPU
acpicpu2 at cpu2: ACPI CPU
acpicpu3 at cpu3: ACPI CPU
acpicpu4 at cpu4: ACPI CPU
acpicpu5 at cpu5: ACPI CPU
acpicpu6 at cpu6: ACPI CPU
acpicpu7 at cpu7: ACPI CPU
timecounter: Timecounter “clockinterrupt” frequency 100 Hz quality 0
ERROR: 1243 cycle TSC drift observed
uhub0 at usb0: vendor 1b6f (0x1b6f) xHCI Root Hub (0000), class 9/0, rev 1.00/1.00, addr 0
uhub0: 2 ports with 2 removable, self powered
uhub1 at usb1: vendor 1b6f (0x1b6f) xHCI Root Hub (0000), class 9/0, rev 2.00/1.00, addr 0
uhub1: 2 ports with 2 removable, self powered
uhub2 at usb2: vendor 1b6f (0x1b6f) xHCI Root Hub (0000), class 9/0, rev 1.00/1.00, addr 0
uhub2: 2 ports with 2 removable, self powered
uhub3 at usb3: vendor 1b6f (0x1b6f) xHCI Root Hub (0000), class 9/0, rev 2.00/1.00, addr 0
uhub3: 2 ports with 2 removable, self powered
IPsec: Initialized Security Association Processing.
uhub4 at usb4: vendor 1002 (0x1002) OHCI root hub (0000), class 9/0, rev 1.00/1.00, addr 1
uhub4: 5 ports with 5 removable, self powered
uhub5 at usb5: vendor 1002 (0x1002) EHCI root hub (0000), class 9/0, rev 2.00/1.00, addr 1
uhub5: 5 ports with 5 removable, self powered
uhub6 at usb6: vendor 1002 (0x1002) OHCI root hub (0000), class 9/0, rev 1.00/1.00, addr 1
uhub6: 5 ports with 5 removable, self powered
uhub7 at usb7: vendor 1002 (0x1002) EHCI root hub (0000), class 9/0, rev 2.00/1.00, addr 1
uhub7: 5 ports with 5 removable, self powered
ahcisata0 port 0: device present, speed: 6.0Gb/s
ahcisata0 port 1: device present, speed: 6.0Gb/s
ahcisata0 port 3: device present, speed: 6.0Gb/s
uhub8 at usb9: vendor 1002 (0x1002) OHCI root hub (0000), class 9/0, rev 1.00/1.00, addr 1
uhub8: 4 ports with 4 removable, self powered
uhub9 at usb8: vendor 1002 (0x1002) OHCI root hub (0000), class 9/0, rev 1.00/1.00, addr 1
uhub9: 2 ports with 2 removable, self powered
uhub10 at usb10: vendor 1002 (0x1002) EHCI root hub (0000), class 9/0, rev 2.00/1.00, addr 1
uhub10: 4 ports with 4 removable, self powered
umass0 at uhub0 port 2 configuration 1 interface 0
umass0: Western Digital (0x1058) Elements 10A8 (0x10a8), rev 3.00/10.42, addr 1
umass0: using SCSI over Bulk-Only
scsibus0 at umass0: 2 targets, 1 lun per target
sd0 at scsibus0 target 0 lun 0: <WD, Elements 10A8, 1042> disk fixed
sd0: fabricating a geometry
sd0: 931 GB, 953837 cyl, 64 head, 32 sec, 512 bytes/sect x 1953458176 sectors
sd0: fabricating a geometry
wd0 at atabus0 drive 0
wd0: <ST3000DM001-1CH166>
wd0: drive supports 16-sector PIO transfers, LBA48 addressing
wd0: 2794 GB, 5814021 cyl, 16 head, 63 sec, 512 bytes/sect x 5860533168 sectors
wd0: GPT GUID: 3954a983-ae2c-44b4-929a-a6f25b77cd1b
dk0 at wd0: “primary”, 5860530176 blocks at 2048, type: <unknown>
wd0: drive supports PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133)
wd0(ahcisata0:0:0): using PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133) (using DMA)
wd1 at atabus1 drive 0
wd1: <KINGSTON SHFS37A240G>
wd1: drive supports 1-sector PIO transfers, LBA48 addressing
wd1: 223 GB, 465141 cyl, 16 head, 63 sec, 512 bytes/sect x 468862128 sectors
wd1: GPT GUID: 54bf64e1-f1ab-40a7-b301-8c0d7b79e0bd
dk1 at wd1: “ec012448-ea24-483b-9df7-c75d116554b1”, 3906 blocks at 2048, type: <unknown>
dk2 at wd1: “965a3f24-5b87-4690-b0e0-2a1e9d629608”, 468854974 blocks at 5954, type: msdos
wd1: drive supports PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133)
wd1(ahcisata0:1:0): using PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133) (using DMA)
wd2 at atabus3 drive 0
wd2: <Hitachi HDS723030ALA640>
wd2: drive supports 16-sector PIO transfers, LBA48 addressing
wd2: 2794 GB, 5814021 cyl, 16 head, 63 sec, 512 bytes/sect x 5860533168 sectors
wd2: GPT GUID: 77d45cf4-beea-49d1-8a3c-93cd7b929ea4
dk3 at wd2: “bb03467d-8bf9-47f8-a3b4-796c7946e9f1”, 5860533101 blocks at 34, type: <unknown>
wd2: drive supports PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133)
wd2(ahcisata0:3:0): using PIO mode 4, DMA mode 2, Ultra-DMA mode 6 (Ultra/133) (using DMA)
uhub11 at uhub7 port 5: vendor 05e3 (0x5e3) USB2.0 Hub (0x608), class 9/0, rev 2.00/9.01, addr 2
uhub11: single transaction translator
uhub11: 4 ports with 4 removable, self powered
ubt0 at uhub4 port 1
ubt0: vendor 0a12 (0xa12) Bluetooth2.1+EDR CLASS1 (0x01), rev 2.00/52.76, addr 2
uhidev0 at uhub11 port 3 configuration 1 interface 0
uhidev0: USB (0x1c4f) USB Keykoard (0x02), rev 1.10/1.10, addr 3, iclass 3/1
ukbd0 at uhidev0
wskbd0 at ukbd0: console keyboard, using wsdisplay0
uhidev1 at uhub11 port 3 configuration 1 interface 1
uhidev1: USB (0x1c4f) USB Keykoard (0x02), rev 1.10/1.10, addr 3, iclass 3/0
uhidev1: 2 report ids
uhid0 at uhidev1 reportid 1: input=2, output=0, feature=0
uhid1 at uhidev1 reportid 2: input=1, output=0, feature=0
uhidev2 at uhub11 port 4 configuration 1 interface 0
uhidev2: Kensington (0x47d) Kensington USB/PS2 Orbit (0x1022), rev 1.10/4.00, addr 4, iclass 3/1
ums0 at uhidev2: 2 buttons
wsmouse0 at ums0 mux 0
pad0: outputs: 44100Hz, 16-bit, stereo
audio1 at pad0: half duplex, playback, capture, mmap
pad0: Virtual format configured – Format SLINEAR, precision 16, channels 2, frequency 44100
spkr2 at audio1: PC Speaker (synthesized)
WARNING: 1 error while detecting hardware; check system log.
boot device: sd0
root on sd0a dumps on sd0b
root file system type: ffs
kern.module.path=/stand/amd64/8.0/modules
P.S. Ethernet addresses were removed from all dmesg log messages.
